Page 335
Controls and Connectors
Monitor Installation and Patient Safety 11-19
M
onitor
Ins
ta
lla
ti
on
a
nd Pa
ti
e
n
t Sa
fe
ty
The Front
Panel of the
M1046B
Computer
Module
The M1046B Computer Module is a component of the M1167A/77A
System. The M1046B has a detachable front panel which must be removed
to view the connectors (except for the ECG Output connector, which is
also visible when the front panel is attached). The connectors on the front
panel of the M1046B Computer Module are shown in the following
diagram:
Maximum Voltages
Rack Connector
60 V
ECG Output
3.2 V p-p
