Controls and Connectors
11-18 Monitor Installation and Patient Safety
M
onitor
Ins
ta
lla
ti
on
a
nd Pa
ti
e
n
t Sa
fe
ty
Connectors of
the M1046A
Computer
Module
The connectors on the front panel of the computer module are:
1. Rack Connector; female interface connector used to connect a
satellite rack to the computer module.
2. ECG Output; used to output an ECG wave to synchronize a
defibrillator and provide an input for the defibrillator marker
signal.
3. Plug-in Module Connectors; female plug-in module connectors,
used to input the information from the plug-in modules to the
integral rack.
Maximum Voltages
(1) Rack Connector 60 V
(2) ECG Output 3.2 V p-p
(3) Module Connectors 60 V
