STAR Line Mode Command Specifications 3-69
ESC * r E n NUL
[Name] Set raster EOT mode
[Code]
ASCII ESC * r E n NUL
Hex. 1B 2A 72 45 n 00
Decimal 27 42 114 69 n 0
[Defined Area]
n = 0, 1, 2, 3, 8, 9, 12, 13, 36, 37
[Initial Value] Models handling full cut: n = 9
Models connected with a presenter: n = 37
[Function] Sets the raster EOT mode.
The EOT mode operates to execute using the raster document quit command (ESC FF EOT).
n is a decimal description (max. 255 digits) using ASCII characters.
Specification A
n FormFeed Cut Feed Cutter Presenter
0 Set To Default Set To Default Set To Default Set To Default
1 ○ -- -- --
2 ○ ○ -- --
3 ○ TearBar -- --
8 ○ -- Full Cut --
9 ○ ○ Full Cut --
12 ○ -- Partial Cut --
13 ○ ○ Partial Cut --
36 ○ -- Full Cut Eject
37 ○ ○ Full Cut Eject
Specification B
n FormFeed Cut Feed Cutter Presenter
0 Set To Default Set To Default Set To Default Set To Default
1 ○ (*1) -- -- --
2 ○ (*1) ○ -- --
3 ○ (*1) TearBar -- --
8 ○ (*1) -- Full Cut --
9 ○ (*1) ○ Full Cut --
12 ○ (*1) -- Partial Cut --
13 ○ (*1) ○ Partial Cut --
36 ○ (*1) -- Full Cut Eject
37 ○ (*1) ○ Full Cut Eject
*1) Form Feed
When the printer is a model handling BM and is set for BM to be effective, the set raster mode page
length is ignored and BM detecting is performed.
