STAR Line Mode Command Specifications 3-5
ESC GS = n1 n2 da1 da2...dak db1 db2...dbk
[Name] Write blank code page data
[Code] ASCII
ESC GS = n1 n2 da1 da2 ... dak db1 db2 … dbk
Hex. 1B 1D 3D n1 n2 da1 da2 ... dak db1 db2 … dbk
Decimal 27 29 61 n1 n2 da1 da2 ... dak db1 db2 … dbk
[Defined Area]
n1= 0
n2 = 48
1≤(n1 + n2 x 256)
0≤da≤255 (Font-A data)
db = 0 (STAR mode is not installed with Font-B.)
k = (n1 + n2 x 256)
[Initial Value] - - -
[Function] A blank code page indicates a character code table where character codes from 80h to FFh
are all blank.
A blank code page can be selected using the ESC GS t n command n = 255.
The printer is reset when writing with this command is completed.
Font-A Data Format Vertical 24 dots x Horizontal 12 dots]
MSB LSB MSB LSB
Da1 ● ● ● ● ● ● ● ● Da2 ● ● ● ● ○ ○ ○ ○
Da3 ● ● ● ● ● ● ● ● Da4 ● ● ● ● ○ ○ ○ ○
Da5 ● ● ● ● ● ● ● ● Da6 ● ● ● ● ○ ○ ○ ○
Da7 ● ● ● ● ● ● ● ● Da8 ● ● ● ● ○ ○ ○ ○
Da9 ● ● ● ● ● ● ● ● Da10 ● ● ● ● ○ ○ ○ ○
Da11 ● ● ● ● ● ● ● ● Da12 ● ● ● ● ○ ○ ○ ○
Da13 ● ● ● ● ● ● ● ● Da14 ● ● ● ● ○ ○ ○ ○
Da15 ● ● ● ● ● ● ● ● Da16 ● ● ● ● ○ ○ ○ ○
Da17 ● ● ● ● ● ● ● ● Da18 ● ● ● ● ○ ○ ○ ○
Da19 ● ● ● ● ● ● ● ● Da20 ● ● ● ● ○ ○ ○ ○
Da21 ● ● ● ● ● ● ● ● Da22 ● ● ● ● ○ ○ ○ ○
Da23 ● ● ● ● ● ● ● ● Da24 ● ● ● ● ○ ○ ○ ○
Da25 ● ● ● ● ● ● ● ● Da26 ● ● ● ● ○ ○ ○ ○
Da27 ● ● ● ● ● ● ● ● Da28 ● ● ● ● ○ ○ ○ ○
Da29 ● ● ● ● ● ● ● ● Da30 ● ● ● ● ○ ○ ○ ○
Da31 ● ● ● ● ● ● ● ● Da32 ● ● ● ● ○ ○ ○ ○
Da33 ● ● ● ● ● ● ● ● Da34 ● ● ● ● ○ ○ ○ ○
Da35 ● ● ● ● ● ● ● ● Da36 ● ● ● ● ○ ○ ○ ○
Da37 ● ● ● ● ● ● ● ● Da38 ● ● ● ● ○ ○ ○ ○
Da39 ● ● ● ● ● ● ● ● Da40 ● ● ● ● ○ ○ ○ ○
Da41 ● ● ● ● ● ● ● ● Da42 ● ● ● ● ○ ○ ○ ○
Da43 ● ● ● ● ● ● ● ● Da44 ● ● ● ● ○ ○ ○ ○
Da45 ● ● ● ● ● ● ● ● Da46 ● ● ● ● ○ ○ ○ ○
Da47 ● ● ● ● ● ● ● ● Da48 ● ● ● ● ○ ○ ○ ○
●
= Data region/
○
=Zero data
