STAR Line Mode Command Specifications
5-9
3. Printer Status
Printer status is the status of the printer sent from the third byte of the automatic status.
Printer status is returned for (transmitted byte count – 2 in Header – 1).
Printer status is always updated for new information. (No log exists.) The following shows the composition of the status.
Bit Contents
Status
Model
Compatability
“0”
“1”
TSP800 TSP700 TSP600 TUP900 TSP1000
TSP828L TSP700II
TSP650
7
Fixed
at
“0”
- - - - - - - - -
6
OFFLINE By Switch Input
No
Yes No No No No No NO NO NO
5 Cover
Status
Closed
Open OK OK OK OK OK OK OK OK
4
Fixed
at
“0”
- - - - - - - - -
3 ONLINE/OFFLINE
Status ONLINE OFFLINE OK OK OK OK OK OK OK OK
2 Conversion
SW
Open
Closed OK OK OK No No NO OK OK
1
Command
Not
Executed Executed OK OK OK OK OK OK OK OK
0
Fixed
at
“0”
- - - - - - - - -
•
Cleared when received at the host (by clearing bit 1 to 0, automatic status is not targeted to occur).
Bit Contents
Status
Model
Compatability
“0”
“1”
TSP800 TSP700 TSP600 TUP900 TSP1000
TSP828L TSP700II
TSP650
7
Fixed
at
“0”
- - - - - - - - -
6
Stopped by high head
temperature
Not stopped
Stopped
OK OK OK OK OK OK OK OK
5 Non-recoverable
Error
No
Yes
OK OK OK OK OK OK OK OK
4
Fixed
at
“0”
- - - - - - - - -
3 Auto-cutter
Error
No
Yes OK OK OK OK OK NO OK OK
2
Mechanical
Error
No
Yes No No No No No NO NO NO
1
Not Used (Fixed at “0”)
-
-
-
-
-
-
-
-
0
Fixed
at
“0”
- - - - - - - - -
Bit Contents
Status
Model
Compatability
“0”
“1”
TSP800 TSP700 TSP600 TUP900 TSP1000
TSP828L TSP700II
TSP650
7
Fixed
at
“0”
- - - - - - - - -
6 Receive
Buffer
Overflow
No
Yes OK OK OK OK OK OK OK OK
5
Command Error (in Page
Mode)
No Yes
OK No No No No NO NO NO
4
Fixed
at
“0”
- - - - - - - - -
3
BM
Error
No
Yes No No No OK OK OK* OK NO
2
Presenter Paper Jam Error
No
Yes
No
No
No
OK
No
NO
NO
NO
1
Head
Up
Error
No
Yes No No No No No NO NO NO
0
Fixed
at
“0”
- - - - - - - - -
• Receive Buffer Overflow
Overflow errors cleared to 0 when returned to host.
• Command Error (in Page Mode)
Command errors cleared to 0 when returned to host.
• BM Error
On models that use a common PE and BM sensor, if a continuous error is detected beyond a determined amount, it
indicates not a black mark error, but a paper out error.
(*) TSP828L (Label Printer) BM errors occur for the following reasons.
