STAR Line Mode Command Specifications 3-35
ESC k n1 n2 d1...dk
[Name] Fine density bit image
[Code]
ASCII ESC k n1 n2 d1 ... dk
Hex. 1B 6B n1 n2 d1 ... dk
Decimal 27 107 n1 n2 d1 ... dk
[Defined Area]
n2 = 0
1 ≤ {(n1 + n2 x 256) x 8} ≤ printable region
k = {(n1 + n2 x 256) x 24}
0≤d≤255
[Initial Value] - - -
[Function] Prints bit images using 1 dot wide and 1 dots high per 1 dot of input data.
The following shows the data processing in this command.
• When {(n1 + n2 x 256) x 8} exceeds the printable region, data after d1 is handled as normal data.
• When {(n1 + n2 x 256) x 8} exceeds the printable region that is currently set, only the data in the
printing region is printed.
At this time, all data for the print region is discarded.
• If the current position already exceeds the print region, this command discards all data.
X Bytes = (n1 + n2 x 256)
d1 d2 • • • • • • • dX
dX x 1 + 1 dX x 1 + 2 • • • • • • • dX x 2
dX x 2 + 1 dX x 2 + 2 • • • • • • • dX x 3
•
• •
• •
•
•
• •
• •
•
24 Dots
dX x 23 + 1 dX x 23 + 2 • • • • • • • dX x 24
bit7 bit6 bit5 bit4 bit3 bit2 bit1 bit0
