STAR Line Mode Command Specifications 3-48
ESC GS EM DC1 m n1 n2
[Name] External buzzer drive pulse condition settings
[Code]
ASCII ESC GS EM DC1 m n1 n2
Hex. 1B 1D 19 11 m n1 n2
Decimal 27 29 25 17 m n1 n2
[Defined Area]
1 ≤ m ≤ 2 49 ≤ m ≤ 50
0 ≤ n1 ≤ 255
0 ≤ n2 ≤ 255
[Initial Value] n1=0 n2=0
[Function] Sets external buzzer derive pulse condition.
m specifies the buzzer drive terminal to perform the condition settings.
m Buzzer Drive Terminal
1, 49 Buzzer Drive Terminal 1
2, 50 Buzzer Drive Terminal 2
n1 specifies the energizing time; n2 specifies the delay time.
• Energizing time:
=20msec x n1
• Delay time: =20msec x n2
Drives for external buzzers set using this command is performed by m n1 n2.
The setting value is not initialized by “@” and .
