STAR Line Mode Command Specifications 3-98
ESC GS * 0 n m1 m2 m3 … mk
[Name] Print mark
[Code] ASCII ESC GS * 0 n m1 m2 m3 … mk
Hex. 1B 1D 2A 30 n m1 m2 m3 … mk
Decimal 27 29 42 48 n m1 m2 m3 … mk
[Defined Area]
“001” ≤ n ≤ ”255”
“0” ≤ m ≤ ”9”
k = n
[Initial Value] - - -
[Function] Prints the mark number specified by m, based on the mark format (mark height, mark line feed
amount, each mark color, and each mark horizontal width) that is preset.
n indicates the number of marks to print; If the number of marks is 10 (m1 to m10), n = “010.”
m specifies the mark number to print.
n and m are ASCII character strings that are represented by decimals; They are composed of
character codes “0” to “9.”
This command is ignored if there is print data in the image buffer. Therefore, other characters
cannot be included (characters, bit images, bar codes, etc.).
If there is no mark specified in the remaining print region, the number of bytes specified by n are
discarded.
Also, if the value of n is out of the defined range, subsequent data are processed as normal data.
This command is affected by position alignment, left margin, moved position, positions such as
horizontal tab and upside down printing.
