3.3.7. Download
ESC & c1 c2 n d1…d48
[Name] Register 12 x 24 dot font download characters
[Code]
ASCII ESC & c1 c2 n d1 ... d48
Hex. 1B 26 c1 c2 n d1 ... d48
Decimal 27 38 c1 c2 n d1 ... d48
[Defined Area]
c1 = 1, 49
c2 = 1, 49
32≤n≤127
0≤d≤255
[Initial Value] - - -
[Function] Registers 12 x 24 dot font download characters to the nth address.
Download characters can be registered to <20>H to <7F>H.
If one has been already registered to an address, it is overwritten.
When parameters c1 and c2 and n are outside of the defined area, subsequent data is handled as
normal data.
d1 ● ● ● ● ● ● ● ● d2 ● ● ● ● ○ ○ ○ ○
d3 ● ● ● ● ● ● ● ● d4 ● ● ● ● ○ ○ ○ ○
d5 ● ● ● ● ● ● ● ● d6 ● ● ● ● ○ ○ ○ ○
d7 ● ● ● ● ● ● ● ● d8 ● ● ● ● ○ ○ ○ ○
d9 ● ● ● ● ● ● ● ● d10 ● ● ● ● ○ ○ ○ ○
d11 ● ● ● ● ● ● ● ● d12 ● ● ● ● ○ ○ ○ ○
d13 ● ● ● ● ● ● ● ● d14 ● ● ● ● ○ ○ ○ ○
d15 ● ● ● ● ● ● ● ● d16 ● ● ● ● ○ ○ ○ ○
d17 ● ● ● ● ● ● ● ● d18 ● ● ● ● ○ ○ ○ ○
d19 ● ● ● ● ● ● ● ● d20 ● ● ● ● ○ ○ ○ ○
d21 ● ● ● ● ● ● ● ● d22 ● ● ● ● ○ ○ ○ ○
d23 ● ● ● ● ● ● ● ● d24 ● ● ● ● ○ ○ ○ ○
d25 ● ● ● ● ● ● ● ● d26 ● ● ● ● ○ ○ ○ ○
d27 ● ● ● ● ● ● ● ● d28 ● ● ● ● ○ ○ ○ ○
d29 ● ● ● ● ● ● ● ● d30 ● ● ● ● ○ ○ ○ ○
d31 ● ● ● ● ● ● ● ● d32 ● ● ● ● ○ ○ ○ ○
d33 ● ● ● ● ● ● ● ● d34 ● ● ● ● ○ ○ ○ ○
d35 ● ● ● ● ● ● ● ● d36 ● ● ● ● ○ ○ ○ ○
d37 ● ● ● ● ● ● ● ● d38 ● ● ● ● ○ ○ ○ ○
d39 ● ● ● ● ● ● ● ● d40 ● ● ● ● ○ ○ ○ ○
d41 ● ● ● ● ● ● ● ● d42 ● ● ● ● ○ ○ ○ ○
d43 ● ● ● ● ● ● ● ● d44 ● ● ● ● ○ ○ ○ ○
d45 ● ● ● ● ● ● ● ● d46 ● ● ● ● ○ ○ ○ ○
d47 ● ● ● ● ● ● ● ● d48 ● ● ● ● ○ ○ ○ ○
bit7 bit6 bit5 bit4 bit3 bit2 bit1 Bit0 bit7 bit6 bit5 bit4 bit3 bit2 bit1 bit0
●: Font data ○: Invalid data
Horizontal 12 Dots
Vertical
24 Dots
