STAR Line Mode Command Specifications
3-42
• n4 bar code height (dot count)
Specification
A
When the height of the bar code is more than the form feed amount, the form feed amount is
automatically doubled.
Specification
B
Form feed at (Bar code height + underbar characters)
• k (Bar code data count), d (Bar code data)
Bar code type Defined area of k
Defined area of d
UPC-E 11≤k≤12 48≤d≤57 (”0”≤d≤”9”)
UPC-A 11≤k≤12 48≤d≤57 (”0”≤d≤”9”)
JAN/EAN8 7≤k≤8 48≤d≤57 (”0”≤d≤”9”)
JAN/EAN13 12≤k≤13 48≤d≤57 (”0”≤d≤”9”)
Code39 1≤k 48≤d≤57 (”0”≤d≤”9”)
65≤d≤90 (”A”≤d≤”Z”)
32, 36, 37, 43, 45, 46, 47 (SP, ”$”, ”%”, ”+”, ”-“, ”.”, ”/”)
ITF 1≤k
When an odd number: 0 is
automatically applied to the
top.
48≤d≤57 (“0”≤d≤”9”)
Code128 1≤k 0≤d≤127
Code93 1≤k 0≤d≤127
NW-7 1≤k 48≤d≤57 (”0”≤d≤”9”)
65≤d≤68 (”A”≤d≤”D”)
36, 43, 45, 46, 47, 58 (”$”, ”+”, ”-“, ”.”, ”/”, ”:”)
97, 98, 99, 100 (”a”, ”b”, ”c”, ”d”)
• UPC – E: k = 11 (or 12)
The
12
th
check digit is automatically applied, so it is specified and ignored.
The command is ignored for data that cannot be shortened.
Automatically converts data to shortened form.
• UPC – A: k = 11 (or 12)
The
12
th
check digit is automatically applied, so it is specified and ignored.
• JAN/EAN – 8: k = 7 (or 8)
The
8
th
check digit is automatically applied, so it is specified and ignored.
• JAN/EAN -13: k = 12 (or 13)
The
13
th
check digit cannot be automatically applied, so it is specified and ignored.
• CODE 39: k is freely set, and maximum value differs according to the mode.
Start/stop code (“*”) is automatically applied.
• ITF: k is freely set, and maximum value differs according to the mode.
If data is oddly numbered, a 0 is applied to the top.
• CODE 128: k is freely set, and maximum value differs according to the mode and the print
character type.
The check character is automatically applied.
• CODE 93: k is freely set, and maximum value differs according to the mode and the print
character type.
The check character (“□”) is automatically applied.
• NW7: k is freely set, and maximum value differs according to the mode and the print character
type.
Start/stop codes included in the data (not automatically applied).
