STAR Line Mode Command Specifications 3-99
ESC GS * 1 h v
[Name] Specify mark height and line feed
[Code] ASCII ESC GS * 1 h v
Hex. 1B 1D 2A 31 h v
Decimal 27 29 42 49 h v
[Defined Area]
“001” ≤ h ≤ ”255”
“001” ≤ v ≤ ”255”
h ≤ v
[Initial Value] Non-volatile memory
[Function] Specifies mark height and line feed amount
h is the mark height (number of dots); v is the line feed amount for the mark (number of dots)
h and v are ASCII character strings that are represented by decimals; They are composed of
character codes “0” to “9.”
If a small line feed amount is specified, missing print can occur, so more than v = 16 dots is
recommended.
ESC GS * 2 m c w
[Name] Specify mark color and mark horizontal width for each mark number
[Code]
ASCII ESC GS * 2 m c w
Hex. 1B 1D 2A 32 m c w
Decimal 27 29 42 50 m c w
[Defined Area]
“0” ≤ m ≤ ”9”
“0” ≤ c ≤ ”1”
“001” ≤ w ≤ ”999”
[Initial Value] Non-volatile memory
[Function] Specifies mark color and mark horizontal width for each mark number.
m specifies the mark number.
c specifies the mark color.
w specifies the mark horizontal width (number of dots).
If w exceeds the currently set print region, this command is ignored.
m, c and w are ASCII character strings that are represented by decimals; They are composed of character
codes “0” to “9.”
c Mark Color
“0” (48) White
“1” (49) Black
