STAR Line Mode Command Specifications 5-8
2. Header -2
Header -2 is the 1 byte length information transmitted from the second byte of the automatic status. The table below
shows the composition of the Header -2.
Header -2 represents the automatic status version (called automatic status version below) using bit 1 to bit 3 and bit 5.
For reference, the table below shows the relationship of actual version bytes and the Header -2. The automatic status
version will be used as new information is added to the printer status bit positions that were empty, by adding new
functions in the future.
When the host does not control the automatic status version, it is acceptable to ignore Header – 2 received.
Bit Contents Status Model Compatability
“0” “1”
TSP800 TSP700 TSP600 TUP900 TSP1000 TSP828L TSP700II TSP650
7 ASB Status Expansion No Expansion Expansion - - - - - - - -
6 Not Used (Fixed at “0”) - - - - - - - - -
5 Version No. OK OK OK OK OK OK OK OK
4 Fixed at “0” - - - - - - - - -
3 Version No. OK OK OK OK OK OK OK OK
2 Version No. OK OK OK OK OK OK OK OK
1 Version No. OK OK OK OK OK OK OK OK
0 Fixed at “0” - - - - - - - - -
Actual automatic status version and header -2 table
Version No. n Header -2
1 00000010B (02 Hex)
2 00000100B (04 Hex)
3 00000110B (06 Hex)
4 00001000B (08 Hex)
5 00001010B (0A Hex)
6 00001100B (0C Hex)
7 00001110B (0E Hex)
8 00100000B (20 Hex)
9 00100010B (22 Hex)
•
•
• •
•
•
30 01101100B (6C Hex)
31 01101110B (6E Hex)
Printer Status Version
Model Name Version No. Status
TSP800 1 (02 Hex) Up to printer status 5 (7 th byte) loaded
1 (02 Hex) Up to printer status 6 (8 th byte) loaded, Ver 4.0 and later
3 (06 Hex) Up to printer status 7 (9 th byte) loaded, Ver 4.3 and later
TSP700 1 (02 Hex) Up to printer status 5 (7 th byte) loaded
1 (02 Hex) Up to printer status 6 (8 th byte) loaded, Ver 3.0 and later
3 (06 Hex) Up to printer status 7 (9 th byte) loaded, Ver 3.2 and later
TSP600 1 (02 Hex) Up to printer status 5 (7 th byte) loaded
1 (02 Hex) Up to printer status 6 (8 th byte) loaded, Ver 3.0 and later
3 (06 Hex) Up to printer status 7 (9 th byte) loaded, Ver 3.2 and later
TUP900 2 (04 Hex) Up to printer status 6 (8 th byte) loaded
3 (06 Hex) Up to printer status 7 (9 th byte) loaded, Ver 1.2 and later
TSP1000 3 (06 Hex) Up to printer status 7 (9 th byte) loaded
TSP828L 3 (06 Hex) Up to printer status 7 (9 th byte) loaded
TSP700II 3 (06 Hex) Up to printer status 7 (9 th byte) loaded
