Star Micronics Line Thermal Printer User Manual
Page 153
―――――――――――――――――――――――――――――――――――――――――――――――――――――――――――――――――――――――――――――
STAR Line Mode Command Specifications
5-12
Bit Contents
Status
By
model
“0”
“1”
TSP800
Ver. 4.3 or
later
TSP700
Ver. 3.2 or
later
TSP600
Ver. 3.2 or
later
TUP900
Ver. 1.2 or
later
TSP1000 TSP828L TSP700II
TSP650
7
Fixed
at
“0”
- - - - - - - - -
6 Not Used (Fixed at “0”)
-
NO NO NO OK NO NO NO NO
5 Not Used (Fixed at “0”)
-
NO NO NO OK NO NO NO NO
4
Fixed
at
“0”
- - - - - - - - -
3 Presenter Paper Position
(See table
below)
NO NO NO OK NO NO NO NO
2 Presenter Paper Position
(See table
below)
NO NO NO OK NO NO NO NO
1 Presenter Paper Position
(See table
below)
NO NO NO OK NO NO NO NO
0
Fixed
at
“0”
- - - - - - - - -
• This status is valid only on models provided with a presenter. Models not provided with a presenter should send this
status fixed at “0.”
• This status is made valid and invalid using the memory switch only on models provided with a presenter.
When valid, the presenter paper position status is updated, but when invalid, the presenter paper position status is fixed
at “0” and there is no change in status.
• Details of the Presenter Paper Position
bit
3
bit
2
bit
1
Presenter Paper Position
0
0
0
Paper position 0 State where there is no paper in presenter
0
0
1
Paper position 1 State where paper is supplied (loop state)
0
1
0
Paper position 2 (Reserved)
0
1
1
Paper position 3 State where paper is discharged (Can be pulled out)
1
0
0
Paper position 4 (Reserved)
1
0
1
Paper position 5 (Reserved)
1
1
0
Paper position 6 State where paper is recovered
1
1
1
Paper position 7 State where paper is pulled out.
• Presenter operation mode: Paper position status transition
Operating
Mode
Paper Presenter
paper
position state transition
Loop
Take-up
Recovery
Position 0 to Position 1 to (Paper cut) to Position 3 to (Paper recovery) to Position 6 to Position 0
Internal
recovery
Pull out
Position 0 to Position 1 to (Paper cut) to Position 3 to (Paper pull out) to Position 7 to Position 0
Loop
Take-up
Recovery
Position 0 to Position 1 to (Paper cut) to Position 3 to (Paper pull out) to Position 6 to Position 0
Front
Discharge
Pull out
Position 0 to Position 1 to (Paper cut) to Position 3 to (Paper pull out) to Position 7 to Position 0
No Loop
Recovery
Position 0 to Position 1 to (Paper cut) to Position 3 to (Paper pull out) to Position 6 to Position 0
Internal
recovery
Pull out
Position 0 to Position 1 to (Paper cut) to Position 3 to (Paper pull out) to Position 7 to Position 0
No Loop
Recovery
Position 0 to Position 1 to (Paper cut) to Position 3 to (Paper pull out) to Position 6 to Position 0
Front
Discharge
Pull out
Position 0 to Position 1 to (Paper cut) to Position 3 to (Paper pull out) to Position 7 to Position 0
Recovery
Invalid
Recovery
Position 0 to Position 1 to (Paper cut) to Position 6 to Position 0
Pull out
Position 0 to Position 1 to (Paper cut) to Position 6 to Position 0
4. Note
Do not use ENQ, EOT, and ESC ACK SOH when automatic status is valid. Invalidate the automatic status in advance
using the DIPSW (memory switch) or the ESC RS a n command to query these.
