Chapter 7. xSeries 226
89
Notes:
1.
May require removing standard devices.
2.
Four SATA HDDs are supported within the installation of the optional ServeRAID-7t controller. Two
HDDs are supported in the standard configuration.
3.
Mixing SATA and SCSI HDDs is not supported.
4.
FAStT options require an optional Fibre controller be installed in the system.
Notes:
1.
Standard HDD is installed in bay 7 on SATA models; bay 9 on SCSI models.
2.
Bays 8 and 9 are available on SCSI models only.
External Storage Expansion Units
4
Form
Factor
-
17331RU
-
EXP400 Storage Expansion Unit
Rack
(3U)
-
17401RU
-
FAStT EXP700 Storage Expansion Unit
Rack
(3U)
-
1724100
-
FAStT100 Storage Server
Rack
(3U)
-
172260U
-
FAStT600 Storage Server
Rack
(3U)
-
17226LU
-
FAStT600 Entry Storage Server
Rack
(3U)
Bay
Form Factor
Height
Front Access
Usage
1
133mm (5.25in)
HH
Yes
Std. Optical
2
133mm (5.25in)
HH
Yes
Optical/Tape
3
89mm (3.5in)
SL
Yes
Std. FDD
4
89mm (3.5in)
SL
Yes
HDD
5
89mm (3.5in)
SL
Yes
HDD
6
89mm (3.5in)
SL
Yes
HDD
7
89mm (3.5in)
SL
Yes
Std. HDD
1
8
2
89mm (3.5in)
SL
Yes
HDD
9
2
89mm (3.5in)
SL
Yes
Std. HDD
1
SBB
Number
Option
Number
Feature
Code
Description
Height
Bays
Supported
1
Max
Qty
2
