Appendix C. UPS runtime estimate (minutes) 509
Notes:
1. Data provided by APC.
Notes:
1.
How-to-Read example for 200-240(208): Input VAC is 200-240 as is the UPS output when electric service
is active. When electric service is interrupted and the UPS is on battery, the UPS output is 208 VAC.
Table 145. IBM UPS750T, 1000T, 1500T Attributes
Tower
Low Voltage Versions (US) UPS750TLV UPS1000TLV UPS1500TLV
New Order Part Number 2130R1X 2130R3X 2130R5X
(Old Order Number) (21301TX) (21303TX) (21305TX)
High Voltage Versions
(Int’l) UPS750THV UPS1000THV UPS1500THV
New Order Part Number 2130R2X 2130R4X 2130R6X
(Old Order Number) (21302TX) (21304TX) (21306TX)
Japan Versions UPS750TJV UPS1000TJV UPS1500TJV
New Order Part Number 2130R7X 2130R8X 2130R9X
(Old Order Number) (21307TX) (21308TX) (21309TX)
UPS Attributes
Communications Links to Servers Serial/USB/Enet Serial/USB/Enet Serial/USB/Enet
Color black black black
APC SmartSlot one one one
Int’l Models
50 or 60Hz, single phase, VAC: 220-240(xxx) 1,2 220-240(xxx) 1,2 220-240(xxx) 1,2
10-Amp, IEC 320-C13 (Device) receptacles 6 8 8
16-Amp, IEC 320-C19 (PDU) receptacles - - -
Receptacles (NEMA L5-20R) - - -
Line Cord Length, NEMA Plug - - -
Line Cord Receptacle (IEC 320-) C14 3 C14 3 C14 3
Low Voltage Versions (US and Japan Models)
50 or 60Hz, single phase, VAC: 100-127(120) 1 100-127(120) 1 100-127(120) 1
Receptacles (NEMA 5-15R) 6 8 8
Receptacles (NEMA L5-20R) - - -
10-Amp, IEC 320-C13 (Device) receptacles - - -
16-Amp, IEC 320-C19 (PDU) receptacles - - -
Line Cord Length, NEMA Plug 6ft, 5-15P 6ft, 5-15P 6ft, 5-15P
Line Cord Receptacle (IEC 320-) - - -
