Appendix F. BladeCenter ® power module upgrade guidelines 533
Result:
• 7.2 IBM power units < 7.4 IBM power units
• Two 1200 W power modules will provide full power redundancy for power domain A
Power domain B worksheet (for power modules 3 and 4)
Result:
• 14.0 IBM power units > 13.4 IBM power units
• Two 2000 W power modules will provide full power redundancy for power domain B
Attention: To maintain proper system cooling, each unoccupied blade bay must contain a filler blade. To
maintain proper module cooling, each unoccupied I/O, management-module, or power-module bay must
contain a filler module. An installed power module must be powered on and must not be used as a filler
module.
Blade bay Description of installed device IBM power units
1 3.06 GHz/533 MHz HS20 blade server with 2 microprocessors 8832-31X 1.6
2 SCSI Storage Expansion Unit 0.4
3 3.06 GHz/533 MHz HS20 blade server with 2 microprocessors 8832-31X 1.6
4 SCSI Storage Expansion Unit 0.4
5 3.06 GHz/533 MHz HS20 blade server with 2 microprocessors 8832-31X 1.6
6 3.06 GHz/533 MHz HS20 blade server with 2 microprocessors 8832-31X 1.6
Total 7.2
Blade bay Description of installed device IBM power units
7 3.06 GHz/533 MHz HS20 blade server with 2 microprocessors 8832-N1X 1.9
8 3.06 GHz/533 MHz HS20 blade server with 2 microprocessors 8832-N1X 1.9
9 3.06 GHz/533 MHz HS20 blade server with 2 microprocessors 8832-N1X 1.9
10 3.06 GHz/533 MHz HS20 blade server with 2 microprocessors 8832-N1X 1.9
11 3.2 GHz/533 MHz HS20 blade server with 2 microprocessors 8832-G1X 1.65
12 2.8 GHz/400 MHz HS40 blade server with 4 microprocessors - first bay (HS40
occupies 2 bays) 8832-41X 1.55
13 2.8 GHz/400 MHz HS40 blade server with 4 microprocessors - second bay (HS40
occupies 2 bays) 8839-41X 1.55
14 3.2 GHz/533 MHz HS20 blade server with 2 microprocessors 8832-G1X 1.65
Total 14.0
