524 COG
Notes:
1.
Adapters rated at a lower frequency than the slots in which they are installed will reduce the bus to the
frequency of the slowest adapter. 133MHz PCI-X adapters are backward compatible with 33/66MHz,
64-bit PCI-based servers.
2. Hot-plug feature only supported in systems with Active PCI slots. For network operating system
support, point your browser to www.pc.ibm.com/us/compat.
3. ServeRAID-6i+ Controller is a PCI-X adapter supporting both Ultra320 and Ultra160 HDDs in a
dedicated or mixed environment, allowing each HDD to perform at rated capacity. The adapter installs
into limited PCI slots and converts both channels of the integrated SCSI controller to RAID in conjunction
with the LSI 1030 chipset. Both standard and the optional SCSI HDD backplanes as well as internal tape
drives and external SCSI devices cabled directly to the onboard controller connectors. Supports up to
1,064MB/s data transfers across the PCI bus with 128MB ECC SDRAMM write-back cache with battery
backup. Supports RAID levels 0, 1, 10, 5, 50 and 1E. The option includes brackets for installation in both
low-profile and standard PCI slots. Internal and external tape drives are supported by ServeRAID-6i+
only when a second channel on the integrated controller is available and the RAID configuration
designates the second channel as a conventional SCSI bus. See system sections for supported tape drives.
4. This adapter is designed using PCI-X technology.
5. ServeRAID-6M (P/Ns 39R8816, 39R8815) are PCI-X adapters powered by a 600MHz Intel xScale
processor, providing 256MB or 128MB of ECC SDRAM battery-backed cache. The dual-channel Ultra320
controller includes two internal 68-pin connectors and two external 0.8mm VHDCI connectors,
supporting up to 14 HDDs on each channel at data transfer rates of up to 1,064MB/s. Supports RAID
levels 0, 1, 10, 1EO, 5, 50 and 5EE with both Ultra160 and Ultra320 HDDs.
6. ServeRAID-7k is available for select systems, installs into a dedicated slot and does not consume a PCI
slot. It works in conjunction with the integrated SCSI controller providing the following RAID levels: 0,
00, 1, 10, 1E, 1E0, 5 and 50 with 256MB of ECC DDR1 battery-backed cache.
7. ServeRAID-7t is a low-profile capable, four-port SATA controller supporting RAID levels 0, 1, 5 and 10.
All ports are internal. ServeRAID-7t is a universal PCI 2.2 compliant adapter powered by Intel’s 400MHz
80302 I/O processor and has 64MB of cache.
System Management 13
03K9309 Advanced System Management Interconnect
Cable Kit
14
- - - - - -
09N7585 Remote Supervisor Adapter 15 Half 32-bit - - Universal 16 33
59P2984 Remote Supervisor Adapter II 17 Half 32-bit - - Universal 16 66
39Y9566 Remote Supervisor Adapter II SlimLine 18 - - - - - -
Communications
1519100 IXA Adapter 19 Full 64-bit - - 3.3v 66
22P5888 PCI Parallel Port Adapter (low profile) Half 32-bit - - 5 33
Remote I/O Expansion
- - - - - - - -
Related I/O Cables
02R2068 Ultra320 Internal Single-drop 24in LVD SCSI
Cable
20
- - - - - -
32P8164 External SCSI Interface Kit 21 - - - - - -
10K3661 USB to Serial Adapter 22, 23 - - - - - -
Option
Number Description
Adapter
Length
PCI
Support 1
Low-
profile
Capable
Hot-
Plug 2
PCI
Voltage
Key MHz 1
