444 COG
Notes:
1.
DS4800 ships standard with eight SFP's which can be used in any of the Host Ports or Expansion Ports.
Up to eight additional SFP's can be ordered to add full support for all ports.
Figure 96. DS4800 rear view
TotalStorage DS4800 hard disk drive (HDD) storage
Notes:
1.
External options may require software upgrades, licenses, etc. Refer to the 'Other Options' table for
possible related options.
Table 116. Additional Features
181580H 181582H 181584H 181588H
Host Partitions (std/max) 8/64 8/64 8/64 8/64
Host Ports (std/max) 8/8 1 8/8 1 8/8 1 8/8 1
Max Redundant Host Connections 4 4 4 4
Expansion Ports (std/max) 8/8 1 8/8 1 8/8 1 8/8 1
Option Number Description
External Storage Expansion Units 1
171010U DS4000 EXP100 Storage Expansion Unit
1740710 DS4000 EXP710 Storage Expansion Unit
181281H DS4000 EXP810 Storage Expansion Unit
Host channels
RS-232
serial port Ethernet ports Dual-ported
drive channels
Host channels
RS-232
serial port
Ethernet ports
Dual-ported
drive channels
Controller A
Controller B
