Chapter 41. TotalStorage DS400 disk system 419
TotalStorage DS400 hard disk drive (HDD) storage
Notes:
1.
External options may require software upgrades, licenses, etc. Refer to the "Other Options" table for
possible required related options.
2. 13 HDDs supported in each EXP400 when attached to DS400. Attachment requires one 0.8mm VHDCI -
to- 0.8mm VHDCI SCSI cable per controller in the DS400. In addition, a second ESM for the EXP400 is
required for redundancy when attached to a dual controller DS400.
Option
Number Description Height Bays Supported
Maximum
Quantity
Ultra320 HDDs
40K1023 73.4GB 10K rpm Ultra320 SCSI HDD SSL 1 ... 14 14
40K1024 146.8GB 10K rpm Ultra320 SCSI HDD SSL 1 ... 14 14
40K1025 300GB 10K rpm Ultra320 SCSI HDD SSL 1 ... 14 14
40K1026 36.4GB 15K rpm Ultra320 SCSI HDD SSL 1 ... 14 14
40K1027 73.4GB 15K rpm Ultra320 SCSI HDD SSL 1 ... 14 14
40K1028 146.8 15K rpm Ultra320 SCSI HDD SSL 1 ... 14 14
39M4566 73.4GB 10K rpm Ultra320 SCSI Express 3-pack SSL 1 ... 14 14
39M4565 146.8GB 10K rpm Ultra320 SCSI Express 3-pack SSL 1 ... 14 14
39M4568 73.4GB 15K rpm Ultra320 SCSI Express 3-pack SSL 1 ... 14 14
External Storage Expansion Units 1
17331RU EXP400 Storage Expansion Unit 2 - - 2
