212 COG
Notes:
1.
A PCI-X riser is required when installing a PCI-X adapter in either slot 1 or slot 2.
2. A PCI-E riser is required when installing a PCI-Express adapter in either slot 1 or slot 2.
Notes:
1.
Slots 1 and 2 required a riser compatible to the adapter being installed.
2. Slots 3 and 4 are low-profile (2U) PCI-E slots that do not require a riser.
System x3650 power and accessories
39Y6101 39Y6098 1486 NetXtreme 1000 Express G Ethernet
Adapter - - - -
39Y6108 39Y6105 1488 PRO/1000 GT Server Adapter by
Intel - - - -
73P5105 73P5101 1579 PRO/1000 GT Dual Port Server
Adapter by Intel - - - -
73P5205 73P5201 1580 PRO/1000 GT Quad Port Server
Adapter by Intel - - - -
System Management
39Y9567 39Y9566 1605 Remote Supervisor Adapter II
Slimline Refresh 1 Half - - -
Other I/O
40K0032 40K1908 4316 PCI/PCI Express Adapter 1 - - - -
40K0028 40K1907 4334 PCI Express Card 2 - - - -
Slot Type Bus Voltage (V) Frequency MHz
Data
Path
Active
PCI
Slot
Length
PCI Slot 1 1 PCI / PCI-X / PCI-E Full-size,
Full-length
1A 3V 133MHz 64-bit No Full
PCI Slot 2 1 PCI / PCI-X / PCI-E Full-size,
Half-length
24 3V 133MHz 64-bit No Half
PCI Slot 3 2 PCI-Express (low profile) 6 - - - No Half
PCI Slot 4 2 PCI-Express (low profile) 16 - - - No Half
SBB
Number
Option
Number
Option
Number Description
Power 1
40K0029 40K1905 1968 x3650 Redundant Power Supply 835 W
Power Distribution Units
- 39Y8938 - 30amp/125V Front-end PDU with NEMA L5-30P connector
SBB
Number
Part
Number
Feature
Code Description
Adapter
Length
PCI
Support
Slots
Supported
Hot-Plug
Capable
