Chapter 18. System x3800 and xSeries 260 223
System x3800 and xSeries 260 memory options
Notes:
1.
The customer can choose up to a total of (4) four memory cards. One Memory Card is standard in the
base. Four memory DIMMs can be selected for each memory card installed.
2. This option kit includes the components necessary to upgrade systems that currently have single-core
Intel Xeon MP processors installed to support the dual-core Intel Xeon MP processors. Processors are not
included in the kit and must be purchased separately.
SBB
Number
Option
Number
Feature
Code Description
Memory Cards 1
39R9502 41Y5000 4338 4-DIMM DDR2 Memory Card
- 41Y5005 - Dual Core X3 Upgrade Kit 2
Memory DIMMs
- 30R5145 - 8GB (2x4GB kit) PC2-3200 CL3 ECC DDR2 Chipkill SDRAM RDIMM
- 39M5809 - 2GB (2x1GB Kit) PC2-3200 CL3 ECC DDR2 SDRAM RDIMM (51
- 39M5812 - 4GB (2x2GB Kit - 8GB Max Memory) PC2-3200 CL3 Double Rank ECC DDR2
SDRAM RDIMM
- 39M5821 - 1GB (2x512MB Kit) PC2-3200 CL3 ECC DDR2 SDRAM RDIMM (256Mb)
73P2874 73P2866 0504 2GB (2x1GB Kit) PC2-3200 CL3 ECC DDR2 SDRAM RDIMM (512Mb)
- 73P2867 - 4GB (2x2GB Kit) PC2-3200 CL3 ECC DDR2 SDRAM RDIMM (512Mb)
30R5147 - 0535 4GB PC2-3200R CL3 ECC DDR2 SDRAM RDIMM
39M5807 - 0552 1GB PC2-3200 CL3 ECC DDR2 SDRAM RDIMM
39M5810 - 0553 2GB PC2-3200 CL3 ECC DDR2 SDRAM RDIMM
39M5819 - 0554 512MB PC2-3200 CL3 ECC DDR2 SDRAM RDIMM
Note: Min (1) pair, Max (8)pair DIMMs are required in pairs. Memory Cards require 2 DIMMs minimum. Memory
Cards support 4 DIMMs each. Standard: 2 GB depending on server model, expandable to 16 GB. Type: 333
MHz, registered, ECC, PC3200 double data rate (DDR) II, SDRAM. Connectors: Two-way interleaved, four dual
inline memory module (DIMM) connectors per memory card. Maximum: Four memory cards, each card
containing two pairs of single-ranked PC3200 DDRII DIMMS.
