106 COG
xSeries 236 memory options
Notes:
1.
Quantity two of each SBB PN must be ordered to equal its corresponding option.
2. Supports Chipkill. Mixing Chipkill DIMMs with nonChipkill DIMMs will disable all Chipkill function.
SBB
Number
Option
Number
Feature
Code Description
Memory DIMMs
90P0870 - 0501 256MB DDR-II SDRAM DIMM (non chip-kill)
- 73P3523 - 512MB (2x256MB) PC2-3200 ECC DDR2 RDIMM Kit
90P1218 - 0502 512MB DDR-II SDRAM DIMM (non chip-kill)
- 39M5818 - 1GB (2x512MB) PC2-3200 ECC DDR2 RDIMM Kit
- 39M5821 - 1GB (2x512MB) PC2-3200 ECC DDR2 RDIMM Kit 2
73P2874 - 0504 1GB PC3200 ECC DDR2 SDRAM RDIMM
- 39M5809 - 2GB (2x1GB) PC2-3200 ECC DDR2 RDIMM Kit 2
73P4794 - 0505 2GB PC2-3200 ECC DDR2 RDIMM SDRAM (chip-kill)
- 39M5815 - 4GB (2x2GB) PC2-3200 Single Rank ECC DDR2 RDIMM Kit
39M5807 - 0552 1GB PC2-3200 CL3 ECC DDR2 SDRAM RDIMM
39M5810 - 0553 2GB PC2-3200 CL3 ECC DDR2 SDRAM RDIMM
39M5813 - 0593 2GB PC2-3200 ECC DDR2 RDIMM SDRAM (chip-kill)
39M5816 - 0541 512MB DDR-II SDRAM DIMM (non chip-kill)
39M5819 - 0554 512MB PC2-3200 CL3 ECC DDR2 SDRAM RDIMM
Note: 16GB of memory is supported via eight DIMM slots. Due to two-way interleaving, installation of memory
DIMMs in matched pairs is required beginning with DIMM slots one and two, then three and four, then five
and six, then DIMM slots seven and eight. Memory-mirroring requires all installed DIMMs to match and
effectively reduces available memory by half. Hot-spare memory requires all installed DIMMs to match except
for the last pair which must be of equal size or greater than other installed pairs.
