Chapter 22. eServer 326m 291
Figure 51. eServer 326m DIMMs
eServer 326m internal SCSI cabling
Hot-Swap SCSI models
eServer 326m hot-swap models contain a DASD backplane supporting two hot-swap, SCA-2-compliant drive
bays. The backplane is connected to the internal connector of the integrated Ultra320 SCSI controller through
a 16-bit low-voltage differential SCSI cable.
Fixed SATA models
eServer 326m non-hot-swap models contain an 80 GB SATA HDD cabled directly to an integrated SATA
controller through a two-drop cable.
Table 54. Standard Memory Configuration
Model Standard DIMM Configuration
46Y,55Y,56Y,65Y,66Y,75Y,76Y,
81Y,82Y,91Y,92Y, 85Y, 86Y
2x512MB PC3200 CL2.5 ECC DDR DRAM RDIMM
67Y, 68Y 4x1GB PC3200 CL2.5 ECC DDR DRAM RDIMM
