Notes:
1.
How-to-Read example for 200-240(208): Input VAC is 200-240 as is the UPS output when electric service
is active. When electric service is interrupted and the UPS is on battery, the UPS output is 208 VAC.
2.
Battery output may be set to 208, 220, 225, 230 or 240 VAC.
3.
Four IEC power cables are provided to attach devices or PDUs to the UPS outlet, which are 2m long with
IEC 320-C19/C20 connectors.
4.
Each outlet is protected by a 15amp circuit breaker.
5.
Requires electrician to connect directly to the terminal block inlet.
Table 150. IBM UPS7500XHV, 10000XHV Attributes
Tower or Rack Mount
Version
UPS7500XHV
UPS10000XHV
UPS Extend Run
Battery Pack
New Order Number
21303RX
21304RX
39Y8857
(Old Order Number)
(21306RX)
(21308RX)
(25R5582)
UPS Attribute
s
Communications Links to Servers
Serial/USB/Enet
Serial/USB/Enet
-
Color
black
black
black
EIA Height
6U
6U
3U
Versions
50 or 60Hz, single phase, VAC:
200-240(xxx)
1, 2
200-240(xxx)
1, 2
--
Maximum power capacity (watts)
6000
8000
--
10 Amp, IEC 320-C13 receptacles
--
--
--
16 Amp, IEC 320-C19 receptacles
4
3, 4
4
3, 4
--
Line Cord Receptacle
terminal block
5
terminal block
5
--
