108
COG
xSeries 236 hard disk drive (HDD) and optical storage options
Notes:
1.
Bays 1 and 2 can be converted to support three additional HDDs for a total of nine HDDs.
2.
Maximum quantity of supported HDDs requires installation of the optical Ultra320 3-Pack HDD kit. Six
HDDs are supported without this kit.
3.
These HDDs are offered for machine type 8841-E2Y.
4.
The Ultra320 3-Pack HDD Kit converts bays 1 and 2 into three additional HDD bays.
5.
An optical drive ships standard in bay 3.
6.
An optical SCSI, RAID or Fibre controller is required in order to attach to the system.
SBB
Number
Option
Number
Feature
Code
Description
Height
Bays
Supported
1
Max Qty
2
Hot-swap Ultra320 HDDs
3
-
32P0727
-
73.4GB 10K rpm Ultra320 SCSI Hot-swap
HDD
SSL
5 ... 10
9
-
32P0728
-
146.4GB 10K rpm Ultra320 SCSI Hot-
swap HDD
SSL
5 ... 10
9
Hot-swap Ultra320 HDDs
90P1386
40K1026
5232
36GB 15K rpm Ultra320 SCSI Hot-swap
HDD
SSL
5 ... 10
9
90P1387
40K1027
5233
73GB 15K rpm Ultra320 SCSI Hot-swap
HDD
SSL
5 ... 10
9
90P1329
40K1023
5202
73.4GB 10K rpm Ultra320 SCSI Hot-swap
HDD
SSL
5 ... 10
9
90P1388
40K1028
5234
146GB 15K rpm Ultra320 SCSI Hot-swap
HDD
SSL
5 ... 10
9
90P1330
40K1024
5203
146.8GB 10K rpm Ultra320 SCSI Hot-
swap HDD
SSL
5 ... 10
9
90P1331
40K1025
5231
300GB 10K rpm Ultra320 SCSI Hot-swap
HDD
SSL
5 ... 10
9
Associated Options
33P3127
33P2751
4221
Ultra320 3-Pack HDD Kit
4
-
1 + 2
3
1
Optical Devices
5
26K8793
32R2906
4104
Multiburner Drive
HH
1 .. 3
2
02R3278
22P6950
4102
DVD-ROM Drive
HH
1 .. 3
2
26K8792
32R2905
4103
48X/32X/48X/16X Max CD-RW/DVD-
ROM Combo Drive
HH
1.. 3
2
External Storage Expansion Units
6
Form Factor
-
17331RU
-
EXP400 Storage Expansion Unit
Rack (3U)
-
171010U
-
FAStT EXP100 Storage Expansion Unit
Rack (3U)
-
17401RU
-
FAStT EXP700 Storage Expansion Unit
Rack (3U)
-
1724100
-
FAStT100 Storage Server
Rack (3U)
-
172260U
-
FAStT600 Storage Server
Rack (3U)
-
17226LU
-
FAStT600 Entry Storage Server
Rack (3U)
