294
COG
Notes:
1.
If a Remote Supervisor Adapter is selected, then PCI-X Riser, SBB 32R2287, is required. The PCI-X
Adapter must be plugged into slot 1 on the PCI-X Riser Card.
2.
If two PCI adapters are selected, one must be a PCI-E half length adapter and it must be plugged into PCI
Slot 2.
40K9098
40K9112
2918
Myricom Myri-10G 2MB PCI Express
Adapter w/ 10GBASE-CX4 Port
Half
PCI-E 8x
1, 2
-
40K9099
40K9113
2919
Myricom Myri-10G 2MB PCI Express
Adapter w/ XAUI-MTP Port
Half
PCI-E 8x
1, 2
-
40K9100
40K9114
2920
Myricom Myri-10G PCI Express
Adapter w/ 10GBASE-SR Port
Half
PCI-E 8x
1, 2
-
40K8840
40K8900
1677
Myricom Myrinet 333MHz Dual Fiber
PCI-X Adapter w/ 2MB Memory
Half
64-bit/
133Mhz
1
-
40K8841
40K8901
2916
Myricom Myrinet 333MHz Single Fiber
PCI-X Adapter w/ 2MB Memory
Half
64-bit/
133Mhz
1
-
40K8842
40K8902
1476
Voltaire 10Gbps Host Channel PCI
Express Adapter
Half
PCI-E 8x
1, 2
-
Systems Management
1
-
39Y9566
-
Remote Supervisor Adapter II Slimline
Refresh 1
Half
32-bit/
33MHz
2
-
-
59P2984
-
73P9341 Remote Supervisor Adapter II
Slimline
Half
32-bit/
33MHz
2
-
Other I/O
32R2287
-
4269
PCI-X Riser Card
1
-
-
-
-
32R2288
-
4270
PCI-E Riser Card
2
-
-
-
-
SLOT
Type
Bus
Voltage (V)
Frequency
MHz
Data Path
Active
PCI?
(Hotswap)
Slot length
Dedicated Raid Slot
-
-
-
-
-
-
-
PCI Slot 1
PCI-X or
PCI-E
-
-
133
-
-
Full
PCI Slot 2
PCI-E
-
-
-
-
-
Half
SBB
Number
Option
Number
Feature
Code
Description
Adapter
Length
PCI
Support
Slots
Supported
Hot Plug
Capable
