Chapter 53. Rack cabinets and options
469
2130R30
UPS3000XLV (US)
2U, 120v, 24a, six IEC C13 outlets, 1 NEMA L5-20R outlet,
includes L5-20P to L5-15R adapter, requires one NEMA L5-30R
wall receptacle
2130R31
UPS3000XHV (US)
2U, 200-240v, 14.25a, seven IEC C13 outlets, 1 IEC C19 outlet,
requires one NEMA L6-20R wall receptacle
32P1692
UPS Extend Run Battery Pack (2U)
2U, up to four may be attached to the UPS3000XLV or XHV to
extend run time when using the batteries
21306RX
UPS7500XHV (US)
6U, 200-240v, 38a, four IEC C19 outlets, requires electrician to
wire to terminal block to single phase 50A wall receptacle
21308RX
UPS10000XHV (US)
6U, 200-240v, 50a, four IEC C19 outlets, requires electrician to
wire to terminal block to single phase 70A wall receptacle
25R5582
UPS Extend Run Battery Pack (3U)
3U, up to four may be attached to the UPS7500XHV or
UPS10000XHV to extend run time when using the batteries
94G6667
Rack Power Cable - C13/NEMA 5-15P
IEC 320-C13 to NEMA 5-15P (14ft)
94G7448
Rack Power Cable - C13/C14
IEC 320-C13 to IEC 320-C14 (14ft)
39Y7938
Rack Power Cable - C13/C20
IEC 320-C13 to IEC 320-C20 (2.8m)
90P4849
Rack Power Cable - C19/C20
IEC 320-C19 to IEC 320-C20 (2.5m)
Mechanical Options:
25R5559
1U Quick Install Filler Panel Kit
Consists of five 1U blank filler panels
25R5560
3U Quick Install Filler Panel Kit
Consists of five 3U blank filler panels
94G7442
Fixed Shelf
Supports up to 100lbs
9306-110
(inches)
9307-xxx
(inches)
9308-xxx
(inches)
Description
Box Footprint
A
20.4
23.6
25.5
Width of rack
B
34.4
39.4
43.5
Depth of rack (not including front stabilizer)
C
21
24/12.5
26
Front/rear door clearance (when required)
Operational Clearance
D
24.4
27.5
29.5
Width of Operational Clearance area
E
74.4
93.4
110
Depth of Operational Clearance area
F
2
2
2
Left/Right sides of rack to Operational
Clearance area
G
30
36
36
Front of rack to Operational Clearance area
H
10
24
26
Rear of rack to Operational Clearance area
Service Clearance
I
26
95.6
97.5
Width of Service Clearance area
J
78.3
129.4
133.5
Depth of Service Clearance area
Rack Options
Option
Number
Description
Information
