130 COG
xSeries 336 memory options
Notes:
1.
Quantity two of each SBB PN must be ordered to equal its corresponding option.
2. Supports Chipkill. Mixing Chipkill DIMMs with nonChipkill DIMMs will disable all Chipkill function.
SBB
Number 1
Option
Number
Feature
Code Memory Options
90P0870 0501 256MB DDR-II SDRAM DIMM (non chip-kill)
73P3523 512MB (2x256MB) PC2-3200 ECC DDR2 RDIMM Kit
90P1218 0502 512MB DDR-II SDRAM DIMM (non chip-kill)
39M5818 1GB (2x512MB) PC2-3200 ECC DDR2 RDIMM Kit
73P2873 0503 512MB PC2-3200 CL3 ECC DDR-2 SDRAM RDIMM
39M5821 1GB (2x512MB) PC2-3200 ECC DDR2 RDIMM Kit 2
73P2874 0504 1GB PC3200 ECC DDR2 SDRAM RDIMM
39M5809 2GB (2x1GB) PC2-3200 ECC DDR2 RDIMM Kit 2
73P4794 0505 2GB PC2-3200 ECC DDR2 RDIMM SDRAM (chip-kill)
39M5815 4GB (2x2GB) PC2-3200 Single Rank ECC DDR2
RDIMM Kit
Note: 16GB of memory is supported via eight DIMM slots. Due to two-way interleaving, installation of memory
DIMMs in matched pairs is required beginning with DIMM slots one and two, then three and four, then five
and six, then the DIMM slots seven and eight. Memory-mirroring requires all installed DIMMS to match and
effectively reduces available memory by half. Hot-spare memory requires all installed DIMMs to match except
for the last pair which must be of equal size or greater than other installed pairs.
Table 23. Standard Memory Configuration
Model Std. DIMM Configuration Chipkill
1xx, 2xx, 3xx, 4xx, 5xY, 05Y, 0WY, 06Y 2 x 512MB PC2-3200 ECC DDR2 RDIMM N
0EY, E1Y, E2Y, E3Y, E4Y, E5Y 2 x 1GB PC2-3200 ECC DDR2 RDIMM Y
