18 COG
Notes:
1.
Model numbers provided are worldwide generally available variant (GAV) model number which are not
orderable as listed and need to be modified by country. The U.S. GAV model numbers use the following
nomenclature: xxU. For example, the U.S. orderable part number for 6223-10Y is 6223-10U. See the
product specific Official IBM announcement letter for other country-specific GAV model numbers. GAV
to MTM mapping for L.A. and A.P. Geographies follow the same pattern. Substitute the last character
with the country-specific designator.
2. Not available from IBM after this date. Business Partner Inventory may be available.
3. Intel Xeon processor with Extended Memory 64 Technology (EM64T), L2 cache and an 800MHz (quad-
pumped) Front Side Bus (FSB).
4. High-speed, two-way interleaved PC2-3200 RDIMMs. Maximum capacity requires replacing the
standard DIMMs. To achieve 16 GB of system memory, when 4 GB PC2-3200 ECC DDR2 RDIMM
memory becomes available, add a 4 GB PC2-3200 ECCDDR2 SDRAM RDIMM in the first four slots.
5. A 5U tower-to-rack conversion kit is available. See ’Power and Accessories.’
6. Broadcom 5721 copper gigabit Ethernet controller with Wake-on-LAN support. Wake-on-LAN is not
supported if systems are improperly shut down.
7. Integrated dual-channel Ultra320 SCSI storage controller on SCSI models, two SATA controllers on SATA
models supporting one SATA HDD per controller. Both the SCSI and SATA integrated controllers
support Integrated ServeRAID-7e (RAID-0 and RAID-1).
8. Maximum storage capacity for SATA models is based on four 250GB SATA HDDs which requires
installation of the optional ServeRAID-7t RAID controller and replacement of the standard HDD.
Standard configuration will support two SATA HDDs.
9. Maximum storage capacity for SCSI models is based on four 146.8GB HDDs.
10. The standard graphics adapter occupies the PCI Express slot. Slot 2 will not be available when using the
3Dlabs Wildcat Realizm 800 graphics adapter.
11. Ships with Red Hat Enterprise Linux WS 3 License. Other models ship preloaded with Microsoft
Windows XP Professional.
IntelliStation Z Pro 6223 processor options
Notes:
1. One additional processor may be installed, providing a maximum of two. All processors must be
identical in type, speed and cache size.
SBB
Number
Option
Number
Feature
Code Processor Options SMP Support 1
39M4300 40K2515 0339 3.0GHz 800MHz 2MB L2 Cache 31Y, 3BY, 3GY, 6GY
39M4054 40K2516 0330 3.2GHz 800MHz 2MB L2 Cache 41Y, 42Y,43Y,4BY
39M4057 40K2517 0333 3.4GHz 800MHz 2MB L2 Cache 12Y, 14Y, 51Y, 52Y, 53Y, 5BY,
5CY, 5GY
39M4069 40K2518 0286 3.6GHz 800MHz 2MB L2 Cache 26Y, 27Y, 64Y, 68Y, 6 BY, 6CY,
6DY, 7GY, E6Y
39Y9910 40K2519 0653 3.8GHz 800MHz 2MB L2 Cache 72Y, 73Y, 75Y, 76Y, 78Y, 7BY,
7CY, 7DY
39Y8713 13N0678 1221 3.8GHz/800MHz-2MB 72Y, 73Y, 75Y, 76Y, 78Y, 7BY,
7CY, 7DY
Note: Z Pro (6223) processor options support Intel’s Extended Memory 64 Technology (EM64T).
