182
COG
Notes:
1.
Hot-Swap SAS/SATA HDDs are installed in the order of Bay 11 as standard then Bay 10, 9, 8,7,6,5,4..
System x3500 I/O options
-
17226LU
-
DS4300 Midrange Disk (6LU)
Rack
(3U)
-
17401xx
-
TotalStorage DS4000 EXP700 Expansion Unit
(all models)
-
-
17101xx
-
TotalStorage DS4000 EXP100 Storage
Expansion Unit (all models)
-
Bay
Form Factor
Height
Front Access
Usage
1
133 mm (5.25in)
-
Y
-
2
133 mm (5.25in)
-
Y
-
3
133 mm (5.25in)
-
Y
-
4
89mm (3.5in)
-
Y
HDD
5
89mm (3.5in)
-
Y
HDD
6
89mm (3.5in)
-
Y
HDD
7
89mm (3.5in)
-
Y
HDD
8
89mm (3.5in)
-
Y
HDD
9
89mm (3.5in)
-
Y
HDD
10
89mm (3.5in)
-
Y
HDD
11
89mm (3.5in)
-
Y
HDD
SBB
Number
Part
Number
Feature
Code
Description
Adapter
Length
PCI
Support
Slots
Supported
Hot-Plug
Capable
1
Storage Controllers
25R8077 25R8064
1670
ServeRAID 8k SAS Controller
-
-
ServeRAID
-
39R8752
39R8743
1680
Ultra320 SCSI Controller 2
-
-
-
-
Networking
30R5205
30R5201
1483
IBM iSCSI Server TX Adapter
Half
32/64-bit
4 ... 6
-
30R5505
30R5501
1481
IBM iSCSI Server SX Adapter
Half
32/64-bit
4 ... 6
-
73P5105
73P5101
1579
PRO/1000 GT Dual Port Server
Adapter by Intel
Half
32/64-bit
4 ... 6
-
39Y6082
39Y6079
1478
NetXtreme 1000 T + Ethernet Adapter
Half
32/64-bit
4 ... 6
-
39Y6091
39Y6088
1497
NetXtreme 1000 S + Ethernet Adapter
Half
32/64-bit
4 ... 6
-
SBB
Number
Option
Number
Feature
Code
Description
Height
Bays
Supported
1
Maximum
Quantity
