Chapter 26. BladeCenter
®
H 8852
323
BladeCenter H 8852 cabling options
Notes:
1.
This cable is 1.5m in length and provides four connections between the optical pass-thru-module (OPM)
and an external Ethernet or fibre environment.
2.
Provides five copper connections between the copper pass-thru module (CPM) and an external gigabit
Ethernet environment. A maximum of 14 connections per CPM is supported. One CPM cable ships with
the CPM option. Two additional cables can be installed.
3.
Option 39Y9170 cannot be installed by manufacturing. It must be shipped separately, as an accessory.
SBB
Number
Option
Number
Feature
Code
Description
Connection
Type From
Connection
Type To
# of
Drops
Connects
From
Connects
To
39Y9173
39Y9171
4364
IBM eServer
BladeCenter Optical
Pass-thru Module SC
Cable (1.5M)
1
Multiport
Optical
SC Duplex
Optical
Connections
4
OPM
switch
SAN
39Y9175
39Y9172
4365
IBM eServer
BladeCenter Optical
Pass-thru Module LC
Cable (1.5M)
Multiport
Optical
LC Duplex
Optical
Connections
4
OPM
switch
SAN
39Y9331
39Y9170
4366
IBM eServer
BladeCenter Copper
Pass-thru Module
Cable
2, 3
Multiport
Copper
CAT 5E
Copper
Connections
5
CPM
switch
Network
32R1854
26R0816
4255
InfiniBand 12x to (3) 4x
Cable 3 meter for IBM
eServer BladeCenter
InfiniBand
4x
InfiniBand
3
IB 12x
connector
IB Fabric
32R1852
26R0813
4296
InfiniBand 4x Cable 3
meter for IBM eServer
BladeCenter
InfiniBand
4x
InfiniBand
1
IB 4x
connector
IB Fabric
32R1849
26R0847
4294
InfiniBand 8 meter 4x
Cable for IBM eServer
BladeCenter
InfiniBand
4x
InfiniBand
1
IB 4x
connector
IB Fabric
32R1850
26R0849
4295
InfiniBand 8 meter 12
to (3) 4x Cable for IBM
eServer BladeCenter
InfiniBand
4x
InfiniBand
3
IB 12x
connector
IB Fabric
32R1938
32R1937
4362
IBM CX4 1.5 Meter
Cable
CX4
Connector
CX4
Connector
1
10Gb
ESM CX4
Port
Another
Nortel 10Gb
ESM or
external
10Gb switch
with CX4
ports.
32R1942
32R1941
4363
IBM CX4 3.0 Meter
Cable
CX4
Connector
CX4
Connector
1
10Gb
ESM CX4
Port
Another
Nortel 10Gb
ESM or
external
10Gb switch
with CX4
ports.
