Chapter 25. BladeCenter
®
chassis 8677
315
Notes:
1.
This cable is 1.5m in length and provides four connections between the optical pass-thru-module (OPM)
and an external Ethernet or fibre environment.
2.
Provides five copper connections between the copper pass-thru module (CPM) and an external gigabit
Ethernet environment. A maximum of 14 connections per CPM is supported. One CPM cable ships with
the CPM option. Two additional cables can be installed.
3.
Option 39Y9170 cannot be installed by manufacturing. It must be shipped separately, as an accessory.
Figure 67.
IBM BladeCenter Copper Pass-thru Module Cable
This IBM BladeCenter option provides connection between the copper pass-thru module and an external
environment. This cable allows up to five copper connections to blade servers. One of these cables included
with each copper pass-thru module. Cable is 3.1m (9.4ft) in length.
39Y9331
39Y9170
4366
IBM eServer
BladeCenter Copper
Pass-thru Module
Cable
Multiport
Copper
CAT 5E
Copper
Connections
5
CPM
switch
Network
32R1849
26R0847
4294
InfiniBand 8 meter 4x
Cable for IBM eServer
BladeCenter
InfiniBand
4x
InfiniBand
1
IB 4x
connector
IB Fabric
32R1850
26R0849
4295
InfiniBand 8 meter 12 to
(3) 4x Cable for IBM
eServer BladeCenter
InfiniBand
4x
InfiniBand
3
IB 12x
connector
IB Fabric
32R1938
32R1937
4362
IBM CX4 1.5 Meter
Cable
CX4
Connector
CX4
Connector
1
10Gb
ESM CX4
Port
Another
Nortel 10Gb
ESM or
external
10Gb switch
with CX4
ports.
32R1942
32R1941
4363
IBM CX4 3.0 Meter
Cable
CX4
Connector
CX4
Connector
1
10Gb
ESM CX4
Port
Another
Nortel 10Gb
ESM or
external
10Gb switch
with CX4
ports.
SBB
Number
Option
Number
Feature
Code
Description
Connection
Type From
Connection
Type To
# of
Drops
Connects
From
Connects
To
