Chapter 49. TotalStorage DS4000 EXP710 fibre channel storage
expansion unit
Notes:
1.
Attachment to a supported Storage Server is required. This expansion unit does not attach directly to the
server.
2.
DS4000 EXP710 accommodates up to four, optional, short-wave SFP modules. The unit ships with two
2.8m/9ft intra-rack power cords (IEC 320-C13 to IEC320-C14).
3.
DS4000 EXP710 Express Model includes four short-wave SFP modules and two 1 meter fiber optic cables.
Notes:
1.
Ships standard with two ESMs, each providing one input port and one output port.
Table 118. TotalStorage DS4000 EXP710 Fibre Channel Storage Expansion Unit At-A-Glance
Name
Pa
rt Nu
mber
Storage Type
HD
D Ba
ys (Std/Max
)
Hot-Swap HD
D B
a
ys (Y
/N)
Max Internal
Storage Capacity
(G
B)
Dimensions (WxDxH
)
Fo
rm
F
a
ct
or
Max Cfg Wt
Pow
e
r Supply
Q
u
antity
(Std/Max)
-
Size
DS4000 EXP710
1,2
174071G
Fibre
Channel
14/14 Y 4.2TB
482mm x 597mm x
132mm (18.97in x
23.52in x 5.21 in)
Rack
Drawer
(3U)
44.47kg
(98.2lbs)
2/2 - 390w
DS4000 EXP710
Express Model
1,2,3
174071J
Fibre
Channel
14/14 Y 4.2TB
482mm x 597mm x
132mm (18.97in x
23.52in x 5.21 in)
Rack
Drawer
(3U)
44.47kg
(98.2lbs)
2/2 - 390w
Table 119. Additional Features
1740-710
ESMs (std/max)
2/2
1
Input Ports (std/max)
2/2
Output Ports (std/max)
2/2
