IBM SCOD-3ZVQ5W User Manual
Page 529
Appendix D. System management overview
521
3. Advanced System Management Scenario
Figure 105. Advanced System Management Scenario
Ethernet LAN
Remote management console
RSAII-host
ASM-node with RSAII installed
ASM-nodes using integrated
ASM ports (RS-485)
RSAII breakout cable
ASM ports (RS-485)
Ethernet cabling
IBM
BMC (shares system ethernet 1)
RSAII-SlimLine (uses dedicated port)
