Chapter 5. xSeries 100 53
Notes:
1.
Model numbers provided are worldwide generally available variant (GAV) model numbers which are
not orderable as listed and need to be modified by country. The U.S. GAV model numbers use the
following nomenclature: xxU. For example, the U.S. orderable part number for 8486-E3Y is 8486-E3U. See
the product specific Official IBM announcement letter for other country-specific GAV model numbers.
GAV to MTM mapping for L.A. and A.P. Geographies follow the same pattern. Substitute the last
character with a country-specific designator.
2. Not available from IBM after this date. Business Partner Inventory may be available.
3. System memory can be expanded to 8GB by installing 2GB DIMM option in each of the four memory
DIMM slots.
4. Wake on LAN is supported.
5. System ships standard with 80GB SATA HDDs.
6. Maximum capacity is based on installation of 250GB SATA HDDs.
7. These models ship with a dual core processor.
xSeries 100 memory options
Notes:
1. Largest value pair should be installed as first pair, next largest value pair should be installed as second
pair, etcetera.
2. If installing DIMMs in pairs, use slots 1 and 3 first, then slots 2 and 4.
SBB
Number
Option
Number
Feature
Code Memory Description
Memory Cards
Memory DIMMs 1, 2
30R5154 30R5148 0530 512MB DDR2 533 DIMM Memory
30R5155 - 0531 1GB DDR2 533 DIMM Memory
- 30R5149 - 2GB (2x1GB) PC2-4200 CL3 ECC DDR2 SDRAM DIMM
30R5156 - 0532 2GB DDR2 533 DIMM Memory
- 30R5150 - 4GB (2x2GB) PC2-4200 CL3 ECC DDR2 SDRAM DIMM
39M5771 - 0536 256MB DDR2 533 DIMM Memory
Table 12. Standard Memory Configuration
Model Std. DIMM Configuration
E3Y, E6Y, EAY, EBY, ECY, EDY, EEY, EFY,
EJY, EKY
1x512MB 533MHz PC2-4200 CL4 ECC DDR2
E1Y 1x256MB 533MHz PC2-4200 CL4 ECC DDR2
