Notes:
1.
All switches are RoHS compliant.
2. ARI port is an RJ45 connector used to connect servers with appropriate console cables (Option P/Ns
31R3130, 31R3132); ACT port is an advanced ARI RJ45 port supporting chaining of servers and virtual
media using Cat5 cables and appropriate conversion cables (Option P/Ns 39M2894, 39M2895, 39M2896,
39M2897).
3. ACI port is an RJ45 connector used for direct connection of this switch up to one of the parent switch's
ARI or ACT ports using Cat5 cable.
Switch Options
Ports Capacity
Standard
Parts
IN OUT Single Switch
Two-level
Tiering
Three-level
Tiering
O
p
ti
o
n
Nu
mb
er
De
scription
1
Switch Type
Type
2
Qty
Type
Qty
ACI
p
o
rts
3
max PS2
KVM servers
max USB
KVM servers
max BladeCenters
ACT ch
ain
s
max swit
che
s
max KVM
servers
max swit
che
s
max KVM
servers
local consoles
rem
o
te co
ns
o
les
1U blank fille
r
panel
1.8m Cat5
cable
Cat5 terminator
EIA moun
ting kit
side-wall
mounting
kit
17351LX 1x8
Console
Switch Enh
KVM
ARI 8 PS2 1 1 8 8 8 - 8 128 - - 1 - 1 - - 1 1
17352LX 2x16
Console
Switch Enh
KVM
ARI 16 PS2 2 1 16 16 16 - 16 256 - - 2 - 1 - - 1 1
17351GX 2x8 Local
Console
Manager
(LCM2)
ACT ACT 8 PS2 or
USB
2 1 128 128 48 8 8 512 64 1024 2 - 1 1 8 1 1
17352GX 2x16
Global
Console
Manager
(GCM2)
ACT ACT 16 PS2 or
USB
1 0 256 256 96 16 16 2048 128 2048 1 2 1 1 16 1 1
LAN 1
17354GX 4x16
Global
Console
Manager
(GCM4)
ACT ACT 16 PS2 or
USB
1 0 256 256 96 16 16 2084 128 2048 1 4 1 1 16 1 1
LAN 1
