Chapter 29. BladeCenter ® HS21 - 8853 347
HS21 - 8853 memory options
HS21 - 8853 hard disk drive (HDD) storage options
Notes:
1.
RAID-1E and 5 requires the optional BladeCenter Storage and I/O Expansion Blade which attaches
directly to the blade server, adding three hot-swap SAS HDD bays and extra expansion slot capacity for a
total of five HDD bays and three expansion card slots.
SBB
Number
Option
Number
Feature
Code Description
39M5780 - 0546 512MB PC2-5300 CL5 ECC DDR2 Chipkill FBDIMM 667MHz
0003901 39M5782 3901 1GB (2x512MB) PC2-5300 CL5 ECC DDR2 Chipkill FB-DIMM
667MHz
39M5783 - 0542 1GB PC2-5300 CL5 ECC DDR2 Chipkill FBDIMM 667MHz
0003904 39M5785 3904 2GB (2x1GB) PC2-5300 CL5 ECC DDR2 Chipkill FB-DIMM
667MHz
39M5789 - 0544 2GB PC2-5300 CL5 ECC DDR2 Chipkill FBDIMM 667MHz
0003909 39M5791 3909 4GB (2x2GB) PC2-5300 CL5 ECC DDR2 Chipkill FB-DIMM
667MHz
39M5795 - 0556 4GB PC2-5300 CL5 ECC DDR2 Chipkill FBDIMM 667MHz
0003915 39M5797 3915 8GB (2x4GB) PC2-5300 CL5 ECC DDR2 Chipkill FB-DIMM
667MHz
SBB
Number
Option
Number
Feature
Code Description Height
Bays
Supported
Max
Qty
SAS HDDs
26K5780 26K5776 5297 36GB 10K SFF SAS Fixed HDD SFF 1, 2 2
26K5781 26K5777 5298 73GB 10K SFF SAS Fixed HDD SFF 1, 2 2
39R7392 39R7388 5152 36GB 10K SAS Hot-Swap HDD SFF 3, 4, 5 1 3
39R7393 39R7389 5153 73GB 10K SAS Hot-Swap HDD SFF 3, 4, 5 1 3
