Chapter 51. Additional fibre channel components 455
Notes:
1.
Provides up to 16 ports in a half-rack width chassis. Ships standard with eight short-wave 4 Gbps SFP
modules, and US power cord.
2. Currently supports short-wave connections only.
3. Includes eight 4GBps SW SFP transceivers and port activation for eight ports.
4. Rack shelf supports up to two SAN16M-2 Express Models.
5. Includes four 4GBps SW SFPs and port activation for four ports.
Notes:
1.
Provides 32 ports in a 1U high chassis. Ships standard with sixteen short-wave 4 Gbps SFP modules, two
rack power cords, two US power cords, and a rail kit.
2. Supports short-wave and long-wave connections.
3. Includes sixteen 4GBps SW SFPs and port activation for 16 ports.
4. Includes eight 4GBps SW SFPs and port activation for eight ports.
5. Long-wave SFP Module operates at 2Gbps transfer rate.
23R1490 LW 4 Gbps 4 km SFP Transceiver
23R1492 LW 4 Gbps 10 km SFP Transceiver
Table 126. IBM TotalStorage SAN32M-2 Express
Option Number Description Ports (Std/Max) SFP Modules (Std)
202632E IBM TotalStorage SAN32M-2 Express 1,2,3 16/32 16
Related Options
22R5907 SAN32M-2 Express Element Manager
22R5909 SAN32M-2 Express SANtegrity Enhanced
22R5911 SAN32M-2 Express Open Trunking (FCP Support
Only)
39M5696 1M LC-LC Fibre Channel Cable
39M5697 5M LC-LC Fibre Channel Cable
39M5698 25M LC-LC Fibre Channel Cable
19K1250 LC-SC Fibre Channel Adapter Cable
22R5906 8-Port FlexPort Expansion Kit 4
19K1272 Long-wave SFP Module 5
23R1490 LW 4 Gbps 4 km SFP Transceiver
23R1492 LW 4 Gbps 10 km SFP Transceiver
Table 125. IBM TotalStorage SAN16M-2 Express Model (continued)
Option Number Description Ports (Std/Max) SFP Modules (Std)
