282 COG
upgraded, the new system model type must be registered with IBM. Directions for registering the new
system model type are included in the option.
14. Minimum two identical HDDs required on primary server (x3950) for OS. HDDs are optional for x3950 E.
Max = 6 HDDs per chassis.
15. One required per chassis for service processor interconnection. The service processors of all chassis must
be connected together via an ethernet network.
Datacenter scalable solution additional options
Table 51. Datacenter Scalable Solution Additional Options
1
Additional, certified options for use with IBM Datacenter solutions.
Option
Number Description Comment
Disk Systems Can be attached to x460, x3950, MXE-460 or x3950 E.
181582H TotalStorage DS4800 Midrange Disk System
181584H TotalStorage DS4800 Midrange Disk System
181588H TotalStorage DS4800 Midrange Disk System
I/O Controllers
24P0960 DS4000 Host Bus Adapter Can be installed in x460, x3950, MXE-460 or x3950 E.
39R8729 ServeRAID-8i SAS Controller 2 Can be installed in x460, x3950, MXE-460 or x3950 E.
31P9601 PRO/1000 MT Server Ethernet Adapter by Intel Can be installed in x460 or in MXE-460.
73P2701 PRO/1000 MT Dual Port Server Ethernet Adapter
by Intel Can be installed in x460 or in MXE-460.
73P4001 NetXtreme 1000SX+ Fiber Ethernet Adapter Can be installed in x460 or in MXE-460.
73P4101 NetXtreme 1000T+ Ethernet Adapter Can be installed in x460 or in MXE-460.
73P4201 NetXtreme 1000T+ Dual Port Ethernet Adapter Can be installed in x460 or in MXE-460.
39Y6088 NetXtreme 1000 SxG Ethernet Adapter Can be installed in x3950 or in x3950 E.
39Y6079 NetXtreme 1000 TxG Ethernet Adapter Can be installed in x3950 or in x3950 E.
39Y6093 NetXtreme 1000 TxG Dual Port Ethernet Adapter Can be installed in x3950 or in x3950 E.
39Y6105 PRO/1000 GT Server Adapter by Intel Can be installed in x3950 or in x3950 E.
39Y8729 ServeRAID-8i SAS Controller Can be installed in x3950 or in x3950 E.
Racks
930842S NetBAY42 Enterprise Rack Cabinet Compatible with x460 and MXE-460.
930842E NetBAY42 Enterprise Expansion Rack Cabinet Compatible with x460 and MXE-460.
93084RX NetBAY42 ER Enterprise Rack Cabinet - 42u
standalone/primary Compatible with x3950 and x3950 E.
93084XX NetBAY42 Enterprise Expansion Rack Cabinet -
42u expansion Compatible with x3950 and x3950 E.
Software Update Subscriptions 3
Note: these are 4 processor subscriptions.
8-way configurations will need quantity two, 16-
way will need four, etc.
4818GAX Software Update Subscription for Microsoft
Windows Server 2003 Datacenter Edition, 32-bit,
4 processor, Scalable, x460 Compatible with x460 and MXE-460.
