X3950 and x460 scalable diagrams – IBM SCOD-3ZVQ5W User Manual
Page 276
268
COG
x3950 and x460 scalable diagrams
Note:
The following sample configurations are for illustration only and may not be suitable for any specific
customer installation. Contact your IBM Business Partner or IBM Marketing Representative for
assistance with your specific configuration requirements.
Figure 48. x3950 and x460 Single Node 8-way Configuration
Figure 49. x3950 and x460 Single Node 16-way Configuration
MXE 460
xSeries 460 (primary server)
Fibre Storage
MXE 460
MXE 460
MXE 460
xSeries 460 (primary server)
Fibre Storage
