Chapter 1. IntelliStation M Pro 6218 9
Notes:
1. A maximum of three HDDs for SAS or SCSI models or four SATA HDDs in SATA models are supported.
The third SAS or SCSI and the fourth SATA HDD must have a optional tray. The fourth SATA HDDs
must come with a ServerRAID 7t card, and all four SATA cables must be connected to the ServerRAID 7t
card.
2. HostRAID does not support the ServerRAID 7t card in SATA models.
Optical Drives
39M6344 32R2905 4139 48X/32X/48X/16X Max CD-RW/DVD-ROM
Combo Drive HH 1,2 2
39M6345 32R2906 4140 IBM Multi-Burner Plus HH 1,2 2
22P1999 22P1999 4149 16X RAM-Read DVD-ROM IDE Drive HH 1,2 2
13N1545 32R2905 4151 IBM 48X/32X/48X/16X Max CD-RW/DVD-
ROM Combination Drive HH 1,2 2
SBB
Number
Option
Number
Feature
Code Description Height
Bays
Supported
Max
Qty
