Chapter 29. BladeCenter
®
HS21 - 8853
Notes:
1.
Model numbers provided are worldwide generally available variant (GAV) model numbers which are
not orderable as listed and need to be modified by country. The U.S. GAV model numbers use the
following nomenclature: xxU. For example, the U.S. orderable part number for 8853-L1Y is 8853-L1U. See
the product-specific Official IBM announcement letter for other country-specific GAV model numbers.
GAV to MTM mapping for A.P. Geographies follow the same pattern. Substitute the last character with a
country-specific designator.
2.
Maximum capacity requires replacing the standard DIMMs. Memory-mirroring, hot-spare memory and
Chipkill functions are supported.
3.
System management functionality, interconnect network connectivity and console connectivity are
managed through the standard management module. The standard integrated service processor
monitors HS21 - MT 8853 system management activity, communicating with the management module in
the BladeCenter.
4.
Dual Broadcom 5708S Gb Ethernet controllers.
5.
Dual-port Broadcom 5714S Gb Ethernet controller. These models have a total of four Gb ethernet ports.
Table 71. BladeCenter HS21 - 8853 At-A-Glance
Pa
rt Nu
mber
1
CPU/FSB Spe
ed (GHz/MHz
)
- Cache
Number of Proc
es
sors (Std/Max)
M
e
mory (Std/Max)
2
Sy
stem Man
a
gement Pr
oces
so
r
3
Inte
grated Ethe
rnet
Storage Control
ler
4
Internal HDD
Interface
Inte
rnal HDD Storage
(Std/Max
)
7
HD
D Ba
ys (Std/Max
)
8
Exp
a
ns
ion Card
s (Std
/Max)
8
8853-L1Y
1.6GHz 1066MHz
2x2MB L2 Dual Core
1/2
1GB/32GB
9
Y
Dual
1GB
4
SAS
Fixed
0/146GB
0/2
0/1
8853-L2Y
1.86GHz 1066MHz
2x2MB L2 Dual Core
1/2
1GB/32GB
9
Y
Dual
1GB
4
SAS
Fixed
0/146GB
0/2
0/1
8853-L3Y
2.0GHz 1333MHz
2x2MB L2 Dual Core
1/2
1GB/32GB
9
Y
Dual
1GB
4
SAS
Fixed
0/146GB
0/2
0/1
8853-L4Y
2.33GHz 1333MHz
2x2MB L2 Dual Core
1/2
1GB/32GB
9
Y
Dual
1GB
4
SAS
Fixed
0/146GB
0/2
0/1
8853-L5Y
2.66GHz 1333MHz
2x2MB L2 Dual Core
1/2
1GB/32GB
9
Y
Dual
1GB
4
SAS
Fixed
0/146GB
0/2
0/1
8853-L6Y
10
3.0GHz 1333MHz
2x2MB L2 Dual Core
1/2
1GB/32GB
9
Y
Dual
1GB
4
SAS
Fixed
0/146GB
0/2
0/1
8853-E1Y
1.6GHz 1066MHz
2x2MB L2 Dual Core
1/2
2GB/32GB
9
Y
Dual
1GB
4
SAS
Fixed
0/146GB
0/2
0/1
8853-E5Y
2.66GHz 1333MHz
2x2MB L2 Dual Core
2/2
4GB/32GB
9
Y
Dual
1GB
4
SAS
Fixed
0/146GB
0/2
0/1
