HS40 processor options
Notes:
1.
Up to three additional processors may be installed, providing a maximum of four. All processors must be
identical in type, speed and cache size.
HS40 memory options
Notes:
1.
BladeCenter HS40 supports up to 16GB of Chipkill memory via 8 DIMM slots. Removal of standard
memory is required to achieve the supported maximum amount.
2.
Due to two-way interleaving, installation of memory options in pairs is required.
HS40 hard disk drive (HDD) storage options
Notes:
1.
Each installed HDD will physically prevent installation of one expansion card.
2.
Integrated mirroring is supported using these HDDs.
3.
The flash disk drives are IDE HDDs and adhere to the same cabling and configuration rules as the
standard IDE HDDs. Both can be installed in the same blade server.
4.
Blade servers support attachment of any one expansion unit.
5.
Supports two SCSI HDDs. See Blade Server Storage and I/O Expansion section for more information.
SBB
Number
Option
Number
Feature
Code
Processor Upgrades
SMP
Support
1
26K4854
13N0656
0312
2.2GHz/400MHz-2MB L3 Cache Xeon Processor MP
5xX
26K4855
13N0655
0313
2.7GHz/400MHz-2MB L3 Cache Xeon Processor MP
6xX
26K4856
13N0654
0314
3.0GHz/400MHz-4MB L3 Cache Xeon Processor MP
7xX
SBB
Number
Option
Number
Feature
Code
Memory Description
1, 2
37L3538
33L5038
0507
512MB PC2100 ECC DDR RDIMM
32P9223
33L5040
0509
2GB PC2100 ECC DDR RDIMM
Note:
DIMMs are installed in matched pairs using the following population order: DIMM1-A &
DIMM1-B, DIMM2-A & DIMM2-B, DIMM3-A & DIMM3-B, DIMM4-A & DIMM4-B.
SBB
Number
Option
Number
Feature
Code
Description
Height
Bays
Supported
Maximum
Quantity
1
IDE HDDs
2
48P7099
25R6906
5213
40GB IDE HDD
Slim
1, 2
2
32P0747
32P0727
5215
73.4GB 10K rpm Ultra320 SCSI Hot-swap HDD
Slim
3, 4
2
32P0748
32P0728
5216
146.4GB 10K rpm Ultra320 SCSI Hot-swap
HDD
Slim
3, 4
2
Storage Expansion
4
26K4852
26K4847
4203
BladeCenter SCSI Storage Expansion Unit
5
-
-
-
13N1675
90P3721
4202
BladeCenter PCI Expansion Unit
-
-
-
