Relay box Receives documents, then relays them to other machines. The
machine that relays the document is called a hub . Your fax machine can either
send to a hub or it can be a hub.

4 elements of an F-Code box

Each F-Code box has the following four elements:

(1) F-Code box number (01-50)

(2) F-Code box name (up to 16 characters)

(3) F-Code sub-address (up to 20 characters - can include numbers and the *and #

characters only)

(4)

. Code (4 digits)

You will choose the information for each of these elements, and enter it into your
machine. The following steps will walk you through entering and changing that informa-
tion.

To create or modify an F-Code box:

Keep pen and paper with you as you follow these steps. As you decide on a sub-
address and enter it into your machine, write it down. Remember to:
(1) write down which box goes with which sub-address, (2) write down any pass-
words or

.codes you enter,

(3) keep these printed records in a safe place.

Press Program key,

, 4, 0, 1,

ENTER

. Depending on whether you already have a

name entered for F-Code box 01, the

LCD

shows:

Use the numeric keypad to enter the two-digit number (01-50) of the F-Code box
you want to create or modify. Here, we ve entered 0,

3 and see either:

If want to select a different F-Code box than the one that appears on the

LCD

, use

the numeric keypad to enter the two-digit F-Code box number now.

Press

ENTER

. What you do next depends on whether you re creating or

modifying the F-Code box:
If creating skip to step 7.
If modifying the

LCD

asks you to enter the proper

code. The

LCD

shows:

Use the numeric keypad to enter the 4-digit

code (not the

ITU

sub-address

and not the

ITU

password) and then press

ENTER

Note:

If you enter an invalid

code, the fax machine rejects the attempt and

aborts this operation.

The machine is now asking you to name this F-Code box. The

LCD

shows:

If you do not want to enter or change this F-Code box s name, skip to step 9.
If you do want to enter or change this F-Code box s name, go on to step 8.

Enter the name by using the one-touch keys. (If necessary, review Entering
characters , page 1.12) An F-Code box s name can be up to 16 characters in
length.

Press

ENTER

to save the box s name and continue. The

LCD

shows:

The fax machine now asks for this F-Code box s sub-address. This is the numeri-
cal identifier you must enter in order to communicate with any remote F-Code
compatible fax.

If you do not want to change an existing sub-address, skip to step 11.

Use the numeric keypad to enter the sub-address to identify this F-Code box.
The sub-address can be up to 20 characters in length and include any
combination of numbers and the * and # characters (but no other non-numeric
characters).

Note:

No other F-Code box in this machine can have the same sub-address as
the one you enter here.

Press

ENTER

to save the sub-address.

Note:

If you entered a sub-address already being used by another F-Code box,
the machine beeps and briefly displays:

The machine now returns you to step 10. Please enter a different number
for your F-Code box s sub-address.

03:Sub-Address No.
Sub-Address In Use

03:Sub-Address No.
654321_

03:Sub-Address No.
123456_

03:Sub-Address No.
_

03:Box Name;Upper
Muratec America_

03:Box Name;Upper
_

03:Set F-Code Box
Enter I.D. Code:****

Select F-Code Box
03:Muratec America

Select F-Code Box
03:No Number Stored

Select F-Code Box
01:NY Branch Office

Select F-Code Box
01:No Number Stored

Advanced features

3.26
