IntelliTrack WMS Architecture
IntelliTrack WMS is built on the three-tier architecture recommended by
Microsoft for client/server environments. Three separate areas integrate to
form your IntelliTrack WMS product: the workstation application, the
server, and the database; thus forming a scalable client/server that can han-
dle a large number of users against a large database. IntelliTrack WMS
minimizes network traffic by shifting transactions to the back end through
a middle tier that provides accessibility to upgrades.
First Tier:
Workstation
Area
The first tier of IntelliTrack WMS is the workstation application and is
comprised of the graphic user interface (GUI objects), including forms,
reports, etc. This is the part of WMS that you use to enter information, gen-
erate reports, etc. The local tables are generated from data provided by the
second tier (middle layer). All transactions (picking, receiving, moves,
Zone Picking
In the RF Portable device,
the user can be assigned a
picking zone, thus limiting
the inventory for picking to
the locations in the assigned
zone.
RF Professional
Receiving, Item
Label Printing,
Container Label
Printing
In the RF Portable device,
print receiving item labels,
putaway item labels, and
newly created container to a
user-selectable network
printer.
RF Professional
RF Standard
Packing Slip Print-
ing
In the RF Portable device,
print Picking Order packing
slips to a user-selectable net-
work printer.
RF Professional
RF Standard
Inventory Letdown
during a Pick Order
on RF Portable
device
In the RF Portable device,
perform an inventory let
down during a pick order
RF Professional
RF Standard
TABLE 1.
IntelliTrack WMS Features by Version (Continued)
Feature
Description
Version
Availability
