SAG581126000 System Application Guide
Issue AD, November 23, 2009 Spec. No. 581126000 (Model 700 NVBA )
Page 98 of 123
This document is property of Emerson Network Power, Energy Systems, North America, Inc. and contains confidential and proprietary information owned by Emerson Network Power, Energy
Systems, North America, Inc. Any copying, use, or disclosure of it without the written permission of Emerson Network Power, Energy Systems, North America, Inc. is strictly prohibited.
Replacement Components
Ordering Notes
1) Refer to the following table. Refer also to "Replacement Components" in
PD588705100/PD588705101/PD588705102/PD588705103/PD588705104.
Item Part Number
Rectifier Module (PCU): Order via List 50 .
DC-DC Converter Module Order via List 62 .
MCA
MCA Main Controller Circuit Card:
MCA Keypad/Display Circuit Card:
MCA Power Supply Circuit Card:
534868 with 534876 Configuration
(
List 10 Standard Configuration)
534868 with 534877 Configuration
(
List 11 Special Application
Configuration)
534868 with 534878 Configuration
(
List 12 Special Application
Configuration)
534868 with 534879 Configuration
(
List 13 Special Application
Configuration.)
288710900
514361
Rectifier Shelf Interface Circuit Card: 535250
MCA Interface Circuit Cards: Order via Lists 72 , 74 , 75 , 76 , 77 , 78
Audible Alarm and Alarm Termination
Circuit Card
Order via List 71
Quad Low Voltage
Disconnect Circuit Card
509477
Interconnect/LVD Inhibit Circuit Card 509532
Quad Shunt POD Circuit Card 507431
Bypass Circuit Card (required for
unused Quad LVD circuit card and
Quad Shunt POD circuit card
mounting positions)
513737
Shunt POD Circuit Card (List RD and
RE Battery Disconnect Assembly with
Shunt)
501981
