System Application Guide
SAG581126000
Spec. No. 581126000 (Model 700
NVBA
)
Issue AD, November 23, 2009
Page 73 of 123
This document is property of Emerson Network Power, Energy Systems, North America, Inc. and contains confidential and proprietary information owned by Emerson Network Power, Energy
Systems, North America, Inc. Any copying, use, or disclosure of it without the written permission of Emerson Network Power, Energy Systems, North America, Inc. is strictly prohibited.
GMT-Type Load Distribution Fuses
Features
♦ An optional “
GMT Load Distribution Fuse Block Assembly Kit
” (see previous section) is available for
additional load distribution.
Restrictions
When used for power distribution, load should not exceed 80% of device rating, except 10 and 15 amp fuses,
for which load should not exceed 70% of device rating.
Ordering Notes
1) Order fuses as required per
.
Ampere Rating
Part Number
Fuse Color
18/100 (GMT-A)
248610301
---
1/4 248610200
VIOLET
1/2 248610300 RED
3/4 248610500
BROWN
1-1/3 248610700
WHITE
2 248610800
ORANGE
3 248610900
BLUE
5 248611000
GREEN
7-1/2 248611300
BLACK-WHITE
10 248611200
RED-WHITE
15 248611500
RED-BLUE
Replacement
Safety Fuse
Cover (GMT-Y)
102774 ---
Replacement
Dummy Fuse
248872600 ---
Table 2
GMT Fuses
