System Application Guide
SAG581126000
Spec. No. 581126000 (Model 700
NVBA
)
Issue AD, November 23, 2009
Page 31 of 123
This document is property of Emerson Network Power, Energy Systems, North America, Inc. and contains confidential and proprietary information owned by Emerson Network Power, Energy
Systems, North America, Inc. Any copying, use, or disclosure of it without the written permission of Emerson Network Power, Energy Systems, North America, Inc. is strictly prohibited.
Manufacturer* Model
Emerson
Network
Power
P/N
Rated 8-Hr.
Capacity
(Ah)
Dimension
W x L x H
(Inches)
Required
Tray
Spacing
Weight
per
battery
(lbs)
C&D
TEL12-160F
140456
157
4.95 x 22.01 x 11.14
7U
115
C&D
TEL12-180F
--
181
4.95 x 22.01 x 12.60
8U
131
Deka Unigy I
12AVR-150ET
122018
150
4.90 x 22.00 x 11.75
8U
115
Douglas
DGS12-150F
125453
150
4.90 x 22.00 x 12.70
8U
137
Douglas
DST12-170F
--
170.8
4.92 x 22.05 x 12.60
8U
129.6
Enersys
PowerSafe
12V155F
122010
155
4.92 x 22.09 x 12.44
8U
148
Fiamm
12FAT125
--
125
4.96 x 21.97 x 10.67
7U
110.23
Fiamm
12FAT155
--
155
4.96 x 21.97 x12.64
8U
132.25
GNB Marathon
M12V125FT
--
125
4.90 x 22.00 x 11.15
7U
105
GNB Marathon
M12V155FT
112795
155
4.90 x 22.00 x 11.15
7U
119
Northstar
NSB170FT
--
167
4.92 x 22.05 x 12.60
8U
131
Battery Manufacturer Information
located at the end of this document.
3) Specify rack spacing of 7U (12.25”) or 8U (14”) between trays and above top tray as required for battery
clearance. See table above.
4) Specify the batteries you intend to use with each List 93 ordered. Lugs for battery connections vary
according to the batteries to be installed. Battery cables will be lugged as shown in the following table.
The table is provided for reference only.
Battery Lug Kit Part Numbers
(Kit provides two lugs for one tray.)
Battery
Specified
Ordered Without
Circuit Breaker
Ordered With
Circuit Breaker
125A or Higher
Ordered With
Circuit Breaker
100A or Lower
C&D TEL12-160F
528235
528235
528234
C&D TEL12-180F
528235
528235
528234
Deka Unigy I 12AVR-150ET
528235
528235
528234
Douglas DG
S12-150F
528237 528237 528236
Douglas DST12-170F
528235
528235
528234
Enersys PowerSafe 12V155F
528235
528235
528234
Fiamm 12FAT125
528235
528235
528234
Fiamm 12FAT155
528235
528235
528234
GNB Marathon M12V125FT
528235
528235
528234
GNB Marathon M12V155FT
528235
528235
528234
Northstar NSB170FT
528235
528235
528234
5) Specify with or without Battery Disconnect circuit breakers. Note: All List 93 trays in a bay will be
furnished with or without Battery Disconnect circuit breakers as specified for the first tray ordered.
