LIST DESCRIPTIONS
List 1: Main Bay Common Equipment (Power and Distribution)
Features
♦ Provides common equipment for one “power and distribution” bay rated for up to 2000 amperes of
distribution.
♦ Accepts one (1) Distribution Cabinet (options are 1-Row, 2-Row, 3-Row, or 4-Row cabinet).
♦ Accepts one (1) Meter-Control-Alarm (MCA) Assembly.
♦ Accepts one (1) Module Mounting Assembly. The Module Mounting Assembly can consist of one (1), two
(2), three (3), or four (4) factory interconnected 8-position Module Mounting Shelves. Each shelf in a
Module Mounting Assembly provides eight (8) mounting positions for Rectifier Modules (PCUs). When a
Module Mounting Shelf within the Module Mounting Assembly is equipped with a DC-DC Converter
Option Kit, the four (4) middle positions will accept either Rectifier Modules (PCUs) or +24V/-48V DC-DC
Converter Modules.
Restrictions
Cannot use a List 21 or 22 in a List 1 when List 1 is used with a List 2
(List 21 and 22 are not provided with connection points for inter-bay busbars.)
Ordering Notes
1) Order a relay rack per ' Relay Racks ' under ACCESSORY DESCRIPTIONS. If required, order Relay Rack
Transition Plates per ' Transition Plates to Mount Relay Rack P/N 543156 on Top of GNB Absolyte IIP
Batteries ' under ACCESSORY DESCRIPTIONS. A ship loose option is available, as described in ' Relay
Racks ' under ACCESSORY DESCRIPTIONS.
2) Order one (1) List 21 , 22 , 23 , or 24 Distribution Cabinet.
3) Order up to four (4) Distribution Bus Panels as required per ' Distribution Bus Arrangements ' and the
capacity of the Distribution Cabinet ordered.
4) Order one (1) List 10 , 11 , 12 , or 13 MCA.
5) Order as required one (1) MCA Interface option per Lists 72 , 74 , 75 , 76 , 77 , or 78 .
Also order as required WinLink Software per List 73 .
6) Order one (1) List 30 (interface components for one (1) Module Mounting Assembly). Order a Module
Mounting Assembly per PD588705101/PD588705102/PD588705103/PD58805104. List 30 is factory
connected to the Module Mounting Assembly ordered.
7) Order one (1) List 60 (DC-DC Converter Option Kit) for each 8-position Module Mounting Shelf in which
DC-DC Converters are required. Note that some Module Mounting Assemblies consist of multiple
8-position Module Mounting Shelves. The kit permits the middle four (4) positions in an 8-position Module
Mounting Shelf to accept DC-DC Converter Modules or Rectifier Modules (PCUs). List 60 is factory
installed within the 8-position Module Mounting Shelf. List 60 kits will be installed starting with bottom
8-position Module Mounting Shelf in the Module Mounting Assembly and working up.
8) Order Rectifier Modules (PCUs) per List 50 as required.
9) Order DC-DC Converter Modules per List 62 as required.
10) Order one (1) Module Mounting Position Blank Cover Panel, Part No. 540959 , for each empty module
mounting position in the system.
11) Order fuses and/or circuit breakers, as required, per ' Distribution Devices ' under ACCESSORY
DESCRIPTIONS.
12) Order input and load distribution lugs, as required, per ' Wiring Components ' under ACCESSORY
DESCRIPTIONS.
