SAG581126000 System Application Guide
Issue AD, November 23, 2009 Spec. No. 581126000 (Model 700 NVBA )
Page 74 of 123
This document is property of Emerson Network Power, Energy Systems, North America, Inc. and contains confidential and proprietary information owned by Emerson Network Power, Energy
Systems, North America, Inc. Any copying, use, or disclosure of it without the written permission of Emerson Network Power, Energy Systems, North America, Inc. is strictly prohibited.
Replacement Alarm, Reference, and Control Fuses
Ordering Notes
1) Order replacement fuses as required per Table 3 (Replaceable Alarm, Reference, and Control Fuses) .
Assembly Desig. Function
Size
(Amperes)
Type Part No.
F1 Subsystem Voltage Monitoring 1-1/3 Bussmann GMT 248610700
F2 System Voltage Monitoring 1-1/3 Bussmann GMT 248610700
F3 Fuse Alarm 1-1/3 Bussmann GMT 248610700
F4 LVD Side A 1-1/3 Bussmann GMT 248610700
F5 LVD Side B 1-1/3 Bussmann GMT 248610700
F6
Converter Fail Alarm Relays
(List 71 only)
1-1/3 Bussmann GMT 248610700
F7 Not Used 5 Bussmann GMT 248611000
F8 Sense Voltage 1-1/3 Bussmann GMT 248610700
F9 Battery Stand Shunt POD Circuit Card 1-1/3 Bussmann GMT 248610700
Interconnect/
LVD Inhibit
Circuit Card
A1
(P/N 509532)
-- -- --
Safety Fuse Cover
(GMT-X)
248898700
FA Fuse Alarm 1/4 Bussmann GMT 248610200
Distribution
Bus Module
with TPH Fuse
Block(s)
-- -- --
Safety Fuse Cover
(GMT-X)
248898700
FA Fuse Alarm 18/100 Bussmann GMT-A 248610301 TPS/TLS
Fuseholders
(P/N 117201)
-- -- --
Safety Fuse Cover
(GMT-X)
248898700
GMT
Fuse Block
Assembly
(P/N 509128)
See “ GMT Load Distribution Fuse Block Assembly Kit ” under ACCESSORY
DESCRIPTIONS for replaceable fuses part numbers.
Table 3
Replaceable Alarm, Reference, and Control Fuses
